- Page 1 NetClock 9483 ® Time and Frequency Synchronization System Option Card Installation Guide 1209-5000-0052 Rev.2, November 2016...
-
Page 2: Table Of Contents
Contents Section A: Introduction – NetClock 9483 ..................1 About this Document ..........................1 Installation Overview ........................2 Unpacking ..............................2 Safety ............................2 Slots / Option Module Bays Layout .................... 3 General Option Card Installation Instructions ................3 Section B: Specific Option Card Installation Instructions ............5 Multi-Gigabit Ethernet Option Card Installation .................. -
Page 3: Section A: Introduction - Netclock 9483
The NetClock 9483 series is a truly flexible Time Server / master clock, also supporting a variety of timecodes (including all NENA formats) and signals to synchronize specific devices. The built-in network port can be supplemented to include 3 additional Gigabit Ethernet (10/100/1000Base-T) ports for synchronizing isolated networks, or for restricting administration to a specific management network. -
Page 4: Installation Overview
The interior of this equipment does not have any user serviceable parts. Contact Spectracom Technical Support if this equipment needs to be serviced. This unit will contain more than one power source if both the AC and DC power options are present. -
Page 5: Slots / Option Module Bays Layout
Each of the available option cards must be installed into a specific Slot in the NetClock 9483 unit in order to function properly (either Slot 2, or Slot 4). Refer to the table below to determine the required installation Slot number for your option card, and then follow the installation instructions outlined in the appropriate section for your option card. - Page 6 Spectracom NetClock The following general instructions describe the steps required to install an option module card into Slot 2 or Slot 4 of a NetClock 9483 unit: • Safely power down NetClock unit and remove chassis cover. CAUTION NEVER install an option card from the back of the unit, ALWAYS from the top.
-
Page 7: Section B: Specific Option Card Installation Instructions
Replace chassis cover, power on the unit. • Log in to NetClock web interface; verify the installed option card is identified by the NetClock. PTP Option Card Installation NOTE: The PTP option card must be installed in Slot 4. NetClock 9483 Option Card Installation Guide, Rev.2... -
Page 8: Reference Priority Input Configuration
Login to the NetClock web interface; verify the installed option card is identified by the NetClock. • If you had backed up your NetClock configuration, optionally restore the previously saved configuration (as previously noted). NetClock 9483 Option Card Installation Guide, Rev.2... -
Page 9: Verifying Hw Detection And Sw Update
If after an installation the card does not appear to be properly identified, it may be necessary to update the NetClock system software to the latest available version. Example STATUS/INPUTS page – NetClock Web UI NetClock 9483 Option Card Installation Guide, Rev.2... -
Page 10: Updating The System Software
Follow the System Software update procedure, as outlined in the main NetClock User Manual under Software Updates. NEXT: Restore your reference priority configuration, as described in the following topic, and configure other option card-specific settings, as described in the main User Manual. NetClock 9483 Option Card Installation Guide, Rev.2... -
Page 11: Technical And Customer Support
If you require further assistance with the configuration or operation of your product, or have questions or issues that cannot be resolved using the information in this document, please contact Spectracom Technical and Customer Support at either our North American or European service centers, or visit the Spectracom website at www.spectracom.com:...
