APPENDIX
Available Formats 1 and 1S are very similar to each other. Most external systems utilizing Data
Format 1 will look for a single-digit day of the month for day 1 through day 9, with a space in
front of each digit ( ^1, ^2, ^3 ... 10, 11... ), whereas other systems need to see a two digit
day of the month for all days 1 through 9 with a leading 0 instead of a space (01, 02, 03...
10, 11...).
If your device requires the two digit day of the month for days 1 through 9 (i.e. 01, 02
etc.), select Format 1.
If your device requires the single digit day of the month for days 1 through 9 (i.e. ^1,
^2, etc.), select Format 1S instead. Refer to "Spectracom Format 1S" on the facing page
for information on Format 1S.
F o r m a t 1 d a t a s t r u c t u r e :
CR LF I ^ WWW ^ DDMMMYY ^ HH:MM:SS CR LF
Where:
CR
LF
I
^
WWW
DD
MMM
YY
HH
:
MM
SS
The leading edge of the first character (
The time synchronization status character (
? When the receiver is unable to track any satellites and the time synchronization lamp is red.
* When the receiver time is derived from the battery backed clock or set manually through the Setup Port
Interface.
250
Carriage Return
Line Feed
Time Sync Status (space, ?, *)
Space separator
Day of Week (SUN, MON, TUE, WED, THU, FRI, SAT)
Numerical Day of Month (01-31)
Month (JAN, FEB, MAR, APR, MAY, JUN, JUL, AUG, SEP, OCT, NOV, DEC)
Year without century (99, 00, 01, etc.)
Hours (00-23)
Colon separator
Minutes (00-59)
Seconds (00-60)
) marks the on-time point of the data stream.
CR
) is defined as described below:
I
