GPS-Denied Environments
VersaSync accommodates an OCXO oscillator, allowing the unit to maintain frequency and
time accuracy for long periods of GPS/GNSS outage. In addition, it can be re-synchronized
by an external reference.
Reliable, Versatile, and Configurable
VersaSync physical inputs and outputs are software configurable and can adapt to various
application requirements. I/O pins can be configured as TTL, 10 V pulse, RS232, RS422, and
RS485. This allows VersaSync to provide a high number of outputs of the same type, while still
fitting into a small form factor. However, if the combination of software configurable outputs is
not enough, VersaSync can accommodate an option board (within the same form factor),
designed to customer requirements to provide additional outputs of the same type or other type
of interface (IRIG AM, etc...).
Due to its high level of ruggedization, VersaSync provides very high intrinsic reliability. Strong
status monitoring capability, either locally or remotely, allows quick fault diagnosis. Physical
alarm (dry contact) and network alarms (SNMP traps) are raised in real time. An internal,
exportable log can be accessed either locally or remotely. In addition to oscillator options
(OCXO), VersaSync is available with a C/A L1 GPS receiver or with an L1/L2 SAASM
receiver. Pulse outputs are configurable through the web user interface ("Web UI"). An exten-
sion slot is available to accommodate additional timing interfaces.
Typical Applications
1.3

Status LEDs

VersaSync's front panel status LEDs provide a real-time status overview: Eight (8) LEDs indicate
the unit's current operating state:
CHAPTER •
1 VersaSync User Manual Rev. 6.0
Airborne : Observation payload (radars, optronics, electronic warfare), flying test bench,
flight analysis
Ground : Satcom On the Move (SOTM), anti-IED jamming systems, mobile radios and
C3I, robotics
Marine : Sensor support (radars, sonars, optronics, electronic warfare), communication
networks, offshore/DSO platforms, buoys
1.3 Status LEDs
