The PTP Statistics Panel
This panel provides statistics for each Ethernet port. If the PTP is set to OFF for a specific port,
this screen will not display any information.
All statistics shown are based on the traffic that is detectable by VersaSync, i.e. in a Unicast
environment, VersaSync may only detect traffic that is addressed to it, based on switch con-
figuration.
Figure 2-8:
2.7.9.2

Enabling/Disabling PTP

To enable or disable PTP:
1.
2.
CHAPTER •
2 VersaSync User Manual Rev. 6.0
Unicast Ttl : [64] Time to live for Unicast packets.
PTP Statistics Panel
PTP Node : IP address of PTP node.
Clock Identity : [e.g., "a0:36:9f:ff:fe:37:b9:5d"]
Domain : Domain number of the selected PTP node.
Unicast : [0,1] OFF or ON (1)
Last Time : [e.g., "2016-08-12 18:19:15"] The last time a packet was received.
Average Rate : [e.g., "0.0624986091344933"] Indicates how often the selected message
has been detected (in seconds e.g., "1.0" would mean once every second).
Navigate to MANAGEMENT > NETWORK: PTP Setup .
In the PTP panel, slide the toggle switch to ON or OFF for the desired Ethernet port
(eth1).
2.7 Configuring Network Settings
109
