The following interfaces are provided:
1.4.1

Input Timing Interfaces

Table 1-3:
1PPS
ASCII/HaveQuick/IRIG B
ASCII/NMEA
Network Interface (10/100/1000bT):
NTP (Stratum 2), PTP
1.4.2

Output Timing Interfaces

Table 1-4:
OUTPUT SIGNAL
10 MHz
1PPS
ASCII/HaveQuick
ASCII/NMEA
NTP server,
PTP v2 master
All Multi I/O interfaces (connector no. 4) are software-configurable, see "Assigning I/O Pins"
on page 36.
For additional information on configuring pinouts, see "Connectors and their Pinouts" on the
next page and "Configuring I/O Settings" on page 40.
1.4.3

Other Interfaces

CHAPTER •
1 VersaSync User Manual Rev. 6.0
Note: VersaSync is highly configurable and the connections can be adjusted
many different ways. Your interface configuration may vary based on options
you selected during the ordering process.
VersaSync inputs
INPUT SIGNAL
VersaSync outputs
Total
available
(1+3)
(2)
(1)
(1)
(1)
USB serial equivalent: CLI interface (Connector 4)
DCLS
Total
RS-232 RS-485 ETH
available
TTL 10V
(1) 1
(1)
(1) 1
(2)
DCLS
RS- 232 RS-485
TTL 10V
SMA
1 1
1
1.4 Interfaces Overview
Connector No.
(see Fig. above)
4
1 4
4
1 5
Connector No.
ETH
(see Fig. above)
2, 3
4
1 4
4
1 5
7
