You can also configure a notification alarm, see "Enabling/Disabling the BroadShield Ser-
vice" on page 140.
BroadShield Web UI Monitoring
The BroadShield Web UI will also display real time signal status information, or a map status.
To open the BroadShield user interface:
1.
2.
DASHBOARD
The Dashboard panel displays up to 7 days of history data, and a real-time amplitude fre-
quency spectrum. The headline background color indicates the current jamming/spoofing
status:
CHAPTER •
3 VersaSync User Manual Rev. 6.0
Note: If at any time you receive an error message
VersaSync Web UI may have timed out (see "Web UI Timeout" on page 197).
Refresh your browser page to log back in.
Navigate to MONITORING > BroadShield . (If you cannot see the MONITORING button
in the Primary Navigation Bar of the HOME screen, this license is not present.)
The embedded Broadshield Web UI will open, displaying the Dashboard and providing
access to the following panels:
red = jamming or spoofing detected;
Failed to connect to the unit
green = no alarms at this time
3.3 Managing References
, the
