3.3 Managing References
1.
Disconnect the GNSS antenna from the VersaSync unit (this is required only when san-
itizing the unit).
2.
Navigate to Interfaces > References: GNSS Reference .
3.
Click on the GEAR button next to the GNSS Reference (typically, there is only one ref-
erence, numbered "0"). The GNSS 0 window will open:
Locate the Delete Position box, check it, and click Submit.
4.
VersaSync will initiate a GNSS self survey.
3.3.3.9

Manually Setting the GNSS Position

The exact geographic position (location and elevation) of the antenna your VersaSync unit—
and thus its onboard GNSS receiver—is a major factor for VersaSync to calculate an accurate
System Time from the GNSS reference.
Normally, the onboard GNSS receiver will track and adjust the antenna position during the so-
called GNSS self survey , which is performed during initial commissioning of a VersaSync unit,
or when rebooting a unit after it had been powered down for some time ("cold start").
162
Note: In Mobile Receiver Mode
the GNSS survey. This feature is only available in
Satellite Mode . In Single Satellite Mode a GNSS survey may take up to 24 hours.
Note: This topic applies only to
or Single Satellite mode.
Note: The elevation (altitude) should be set in accordance with the World Geo-
detic System 1984 ( WGS 84
it is NOT possible to delete the position and start
Standard Mode
stationary applications
), not Mean Sea Level (MSL).
CHAPTER •
3
and in Single
, i.e. to Standard mode,
VersaSync User Manual Rev. 6.0
