Accessories Available

For accessories not listed in this section, refer to the configuration guide for your analyzer
or refer to the following Internet site:
www.hp.com/go/8720

Measurement Accessories

Accessories are available in these connector types: 2.4-mm, 3.5-mm, 7-mm, 50-ohm type-N,
and 7-16.
Test port cables are used to connect to the device under test. Calibration kits include
standards, such as open/short circuits and loads, which are measured by the network
analyzer for increased measurement accuracy. Electronic calibration (ECal) modules are
used with the ECal PC interface kit to provide automated calibration (in place of a
calibration kit). A verification kit is used to verify system performance.

Test-Port Cables: 3.5-mm

• HP 85131C single, semi-rigid: 3.5-mm to 3.5-mm, 81-cm (32-in).
For the HP 8719ET/ES or HP 8720ET/ES.
• HP 85131D set, semi-rigid: 3.5-mm to 3.5-mm, 53-cm (21-in) each.
For the HP 8719ET/ES or HP 8720ET/ES.
• HP 85131E single, flexible: 3.5-mm to 3.5-mm, 96-cm (38-in).
For the HP 8719ET/ES or HP8720ET/ES.
• HP 85131F set, flexible: 3.5-mm to 3.5-mm, 53-cm (21-in) each.
For the HP 8719ET/ES or HP 8720ET/ES.
• HP 85132C single, semi-rigid: 7-mm to 3.5-mm, 81-cm (32-in).
For the HP 8719ET/ES or HP 8720ET/ES.
• HP 85133C single, semi-rigid: 2.4-mm, 81-cm (32-in).
For the HP 8722ET/ES.
• HP 85133D set, semi-rigid: 2.4-mm, 53-cm (21-in) each.
For the HP 8722ET/ES.
• HP 85133E single, flexible: 2.4-mm, 96-cm (38-in).
For the HP 8722ET/ES.
• HP 85133F set, flexible: 2.4-mm, 53-cm (21-in) each.
For the HP 8722ET/ES.
• HP 85134C single, semi-rigid: 3.5-mm to 2.4-mm, 81-cm (32-in).
For the HP 8722ET/ES.
• HP 85134D set, semi-rigid: 3.5-mm to 2.4-mm, 53-cm (21-in) each.
For the HP 8722ET/ES.
• HP 85134E single, flexible: 3.5-mm to 2.4-mm, 96-cm (38-in).
For the HP 8722ET/ES.
