Keyboard Template - HP 8719ET Reference Manual

Options and Accessories
Accessories Available

Keyboard Template

The analyzer is designed to accept most PC-AT-compatible keyboards with a mini-DIN
connector. The keyboard can be used for control or data input, such as titling files. The
information found on the analyzer keyboard template (HP part number 08753-80220) is
also listed in Table 7-1.
Table 7-1 Keyboard Template Definition
Keyboard Analyzer Function
Key Name
F1 Softkey 1
F2 Softkey 2
F3 Softkey 3
F4 Softkey 4
F5 Softkey 5
F6 Softkey 6
F7 Softkey 7
F8 Softkey 8
F9 x1
F10 k/m
F11 M/µ
F12 G/n
Shift F1 CHAN 1
Shift F2 CHAN 2
Shift F3 MEAS
Shift F4 FORMAT
Shift F5 SCALE
Shift F6 DISPLAY
Shift F7 AVG
7-12
Keyboard Analyzer Function
Key Name
Shift F8 CAL
Shift F9 MARKER
Shift F10 MARKER SEARCH
Shift F11 MARKER FUNCTION
Shift F12 SEQ
Ctrl F1 CHAN 3
Ctrl F2 CHAN 4
Ctrl F3 POWER
Ctrl F4 SWEEP SETUP
Ctrl F5 START
Ctrl F6 STOP
Ctrl F7 CENTER
Ctrl F8 SPAN
Ctrl F9 SYSTEM
Ctrl F10 LOCAL
Ctrl F11 COPY
Ctrl F12 SAVE/RECALL
Alt F1 TITLE
