Instrument Specifications

Uncorrected Port Performance

Table 2-5 3.5-mm (50 Ω) Device Connector Type
HP 8719/20ET (3.5-mm, 50 Ω)
Description
a
Directivity (dB)
a
Source Match (dB)
a
Load Match (dB)
Reflection
b
Tracking (dB)
a
Transmission
Tracking (dB)
Tracking Stability
(Ratio Measurement)
Magnitude (dB)
Phase (deg)
c
Crosstalk (dB)
a. Does not include effects of cable on test ports.
b. Does not include rolloff below 500 MHz which is typically −18 dB at 100 MHz, and
−25 dB at 50 MHz.
c. Measurement conditions: Normalized to a thru, measured with two shorts, 10 Hz IF
bandwidth, averaging factor of 8, alternate mode, source power set to the lesser of the
maximum power out or the maximum receiver power.
HP 8719/20/22ET Specifications and Characteristics
50 to 500 MHz 0.5 to 2 GHz
24
16
22
± 3
± 3
0.02/˚C, typ. 0.03/˚C, typ.
0.1/˚C, typ. 0.1/˚C, typ.
101
Instrument Specifications
Specification
2 to 8 GHz
27 21
20 14
22 22
± 3 ± 3
± 3 ± 3
0.03/˚C, typ.
0.3/˚C, typ.
101 101
8 to 20 GHz
16
11
17
± 3
± 3
0.04/˚C, typ.
0.5/˚C, typ.
93
