Corrected System Performance (HP 8719/20ES)

The specifications in this section apply for measurements made using 10 Hz IF bandwidth,
no averaging, and at an environmental temperature of 23 ±3 °C, with less than 1 °C
deviation from the calibration temperature. Assumes that an isolation calibration was
performed with an averaging factor of 8.
Table 1-1 System Dynamic Range, All Device Connector Types
HP 8719/20ES, All Cal Kits, All Cables, 10 Hz IF BW
Description
System Transmission Dynamic Range
HP 8719/20ES (Standard)
50 MHz to 840 MHz
840 MHz to 8 GHz
8 GHz to 20 GHz
HP 8719/20ES (Option 007)
50 MHz to 840 MHz
840 MHz to 20 GHz
HP 8719/20ES (Option 012 with test set bypassed)
50 MHz to 500 MHz
500 MHz to 2 GHz
2 GHz to 8 GHz
8 GHz to 13.5 GHz
13.5 GHz to 20 GHz
a. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as 3
standard deviations above the mean of the linear magnitude noise floor trace
over the specified frequency band.
b. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as
the mean of the linear magnitude noise floor trace over the specified frequency
band.
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
a
a
Specification Supplemental
Information
77 dB
100 dB
100 dB
82 dB
105 dB
b
115 dB, typ.
115 dB, typ.
115 dB, typ.
113 dB, typ.
113 dB, typ.
