5. When you select either a radio button or a checkbox for an addressee, the floating
box that contains the input numbers is displayed on the Input Settings/Options
screen. Select the inputs that need monitoring by clicking on their numbers in this box.
Selected input numbers are displayed in white on a blue field.
To deselect an input number, click on it again.
Figure 82.
6. Use the radio buttons associated with each addressee to select whether the addressee
will be e-mailed about failures, fixes, both, or will not be notified. The None radio
button is useful for temporarily removing personnel from the e-mail list when they are
unavailable, such as when traveling or on vacation.
7. If desired, click the Send test E-mail button to test the e-mail function.
8.
Click the Take button for the e-mail address changes to take effect.

Updating the Firmware

The firmware upgrade utility provides a way to replace the firmware that is coded on the
DXP control board without needing to take the switcher out of service, open its enclosure,
and replace the firmware chip.
Update the DXP firmware as follows:
NOTE: The update firmware utility is for replacing the firmware that controls all switcher
operation. This is not the page to insert your own HTML pages. See
Unmuting Video and Audio Outputs
1. Go to the Extron website, www.extron.com, and download the latest firmware file to
your computer.
a.
On the Extron web page, select the Downloads tab.
b. On the Download Center page, click the Firmware link on the left sidebar
menu.
c. Click on the name of your DXP switcher.
d. On the next screen, fill in the required information, then click the Download
product name_firmware version.exe button.
e. In the File Download - Security Warning window, click Save.
f. In the Save As window, browse to the folder where you want to save the firmware
file, and click Save. The firmware installation file is placed on your hard drive.
Selecting Inputs to Monitor
on page 36 to insert custom HTML pages.
DXP DVI Pro and DXP HDMI Series • Matrix Software
Muting and
88
