Saving and Recalling Presets

The current configuration (0) can be saved as a preset in any one of 32 preset memory
addresses. Preset locations are assigned to the input buttons and (where necessary)
output buttons. Up to 16 presets can be selected from the front panel to be either saved or
retrieved (16 additional presets can be selected via the control software, SIS commands,
or the web pages). When a preset is retrieved from memory, it becomes the current
configuration.
NOTES:
Preset
Preset
NOTE: Presets 17 through 32 are available via
Figure 36.
• Presets cannot be viewed from the front panel unless recalled as the current
configuration. Presets can be viewed using the Matrix Switchers Control Program
Presets menu (see page 91).
•
The current configuration and all presets are stored in non-volatile memory.
When power is removed and restored, the current configuration is still active and all
presets are retained.
• When a preset is recalled, it replaces the current configuration, which is lost
unless it is also stored as a preset. The recalled preset overwrites all of the current
configuration ties in favor of the preset ties.
• All models have 32 presets; however, only up to 16 presets (the number of front
panel buttons) can be selected from the front panel. Preset numbers greater than
16 can be accessed under serial port or Ethernet control.
Preset Preset Preset Preset Preset
1 2 3 4 5 6
INPUTS
1 2
3 4 5 6
1 2
3 4 5 6
OUTPUTS
Preset
Preset Preset Preset Preset
9 13
10 11 12 14
RS-232/RS-422 and Ethernet control only.
Preset Locations for All DXP Models
Preset Preset
7 8
7 8
7 8
Preset Preset
15 16
DXP DVI Pro and DXP HDMI Series • Operation 29
