Introduction

This section gives an overview of the Extron DXP Series Digital Matrix Switchers, describes
significant features of the series, and provides application diagrams.
•
•
•
•

About this Guide

This guide contains installation, configuration, and operating information for the DXP Series
Digital Matrix Switchers, including the DXP DVI Pro series and the DXP HDMI series.
The terms "DXP," "switcher," and "DXP switcher" are used interchangeably in this guide to
refer to all DXP models. "DXP DVI Pro" refers to the four DVI Pro models, and "DXP HDMI"
refers to the four HDMI models.

About the DXP DVI Pro and DXP HDMI Series Digital Matrix Switchers

The DXP DVI Pro and DXP HDMI series are high performance, digital matrix switchers. The
DVI Pro series route single link DVI-D signals (up to eight) and the DXP HDMI series route
HDMI signals from multiple sources to any DVI- or HDMI-equipped display devices. All DXP
matrix switchers support resolutions of up to 1920x1200 and HDTV 1080p/60.
The DVI Pro and HDMI models are HDCP compliant, enabling simultaneous distribution of a
single source signal to one or more compliant displays.
The following matrix sizes are available:
DXP DVI Pro Series:
•
•
•
•
DXP HDMI Series:
•
•
•
•
All three series provide easy integration in applications that require reliable DVI Pro or HDMI
signal routing. They include several convenience features that are common to most Extron
matrix switchers, such as the QuickSwitch Front Panel Controller (QS-FPC
IP Link, and Ethernet control.
About this Guide
About the DXP DVI Pro and DXP HDMI Series Digital Matrix Switchers
Features
Application Diagrams
DXP 44 DVI Pro: 4 inputs by 4 outputs
DXP 48 DVI Pro: 4 inputs by 8 outputs
DXP 84 DVI Pro: 8 inputs by 4 outputs
DXP 88 DVI Pro: 8 inputs by 8 outputs
DXP 44 HDMI: 4 inputs by 4 outputs
DXP 48 HDMI: 4 inputs by 8 outputs
DXP 84 HDMI: 8 inputs by 4 outputs
DXP 88 HDMI: 8 inputs by 8 outputs
DXP DVI Pro and DXP HDMI Series • Introduction
), global presets,
™
