Configuration Worksheets

Instead of trying to remember the configuration for each preset, use worksheets to record
this information. Make copies of the blank
sheet for each preset configuration. Cross out all unused or inactive inputs and outputs.
The worksheet is generic for all models of DXP. Disregard or cross out boxes for inputs and
outputs that your switcher does not have.

Worksheet Example 1: System Equipment

Figure 66 shows a worksheet for a DXP in a fictional organization with the system hardware
annotated. Output 7 has no connection in this organization, so it has been crossed out on
the worksheet.
DVI PRO/
Camera #1
Main hall
Figure 66.
Inputs include VTRs, editing stations, DVI Pro/HDMI cameras, and an Extron VTG 400DVI.
Output devices include various DVI Pro/HDMI monitors.
The VTG 400DVI video test generator connected to input 6 enables a video test pattern to
be sent to one, several, or all output devices for problem isolation or adjustment purposes.
Input Sources
DVI PRO/ DVI PRO/ VTR
HDMI HDMI HDMI #1
Camera Camera
Main #2 #3
podium
1 1 2 3 4
1 2 3 4
Main hall Podium Conf.
#1 #2 monitor Room
#1
Output Destinations
3 Weekly status mtg
Preset # Title:
Fill in the preset number and use colors, dashes, and so forth to make connecting lines.
Worksheet Example 1: System Equipment
Worksheet Form
VTR VTG Editing Editing
400DVI Station
#2 Station
#1
#2
5 6 7 8
5 6 7 8
Podium Demo Lobby
monitor Room monitor
#2
Video ties:
