Matrix Software

This section discusses the following topics:
•
•
The following software programs are available at www.extron.com:
•
•
Both programs are compatible with Windows
Windows.

Matrix Switchers Control Program

NOTES:
Matrix Switchers Control Program
Button Label Generator
The Extron Matrix Switcher Control Program, which communicates with the switcher via
the RS-232/RS-422 port and the Ethernet port, and provides an easy way to set up ties
and sets of ties
The Extron Button Label Generator, which enables you to design and print labels for the
DXP front panel buttons
•
The program controls most Extron matrix switchers. However, its operation is limited
to the features and configuration of your DXP.
• The DXP switcher can support either RS-232 or RS-422 serial communication
protocol from the rear panel Remote RS232/RS422 port, and RS-232 from the
front panel Config port. The DXP operates at 9600, 19200, 38400, or 115200 baud
rates. See Selecting the RS-232/RS-422 Port Protocol and Baud Rate (Rear
Panel) on page 44 to configure the Remote RS232/RS422 and Config ports
using the front panel buttons.
2000, Windows XP
®
DXP DVI Pro and DXP HDMI Series • Matrix Software
, and later versions of
®
73
