Mycom S CPM 153
"
Endress+Hauser
3
Installation
3.1
Incoming acceptance, transport, storage
• Make sure the contents are undamaged! If any damage is found, inform your postal
service, freight handler or forwarding agent. Keep any damaged goods until matters
have been clarified.
Check that the scope of delivery is complete.
• For storage and transport purposes, pack the instrument so that it is protected against
impacts and humidity. The original packaging offers the best protection. Also, keep to
the approved ambient conditions (see "Technical data").
• If you have any questions, please contact your supplier or your nearest
Endress+Hauser sales centre (see the back page of these Operating Instructions).
3.2
Installation conditions
3.2.1
Installation dimensions
You can find the dimensions and length of the transmitter in the
"Technical data" on page 110 ff.
3.3
Installation
3.3.1
Installation instructions
• The standard installation method for the CPM 153 transmitter is as a field instrument.
• The CPM 153 transmitter can be fixed to vertical or horizontal posts using the round
post fixture available from Endress+Hauser (see "Accessories"). When installing the
instrument outdoors, you also require the weather protection cover CYY 101. This
cover is compatible with all field instrument installations options.
• Always mount the transmitter horizontally so that the cable entries point downwards.
• The transmitter can be installed as a panel-mounted unit as well.
3.3.2
Wall mounting
Caution!
• Check that the temperature does not exceed the maximum permitted operating
temperature range (–20° ... +60°C). Install the instrument in a shady location. Avoid
direct sunlight.
• Mount the wall mounting housing so that the cable entries always point downwards.
3 Installation
9
