9 Accessories
pH/redox electrodes
Rinse connection
adapter
Spray cleaning system
Service adapter
Optoscope
Terminated
pH measuring cable
108
Type
Universally applicable, very easy to clean and
OrbiSint W
CPS 11/12/13 insensitive to soiling due to PTFE diaphragm, pressures
up to 6 bar, conductivity > 50 µS/cm
Technical Information:
TI 028C/07/en, Order No.: 50054649
Electrodes with ceramic diaphragms and KCl liquid
CeraLiquid P
CPS 41/42/43 electrolyte, use with counterpressure, explosion-proof up
to 8 bar
Technical Information:
TI 079C/07/en, Order No.: 50059346
Gel electrode with double-chamber reference system.
CeraGel P
CPS 71/72 Long-term stability, short response time, very long toxic
path, resistant to alternating temperature and pressure
cycles
Technical Information:
TI 245C/07/en, Order No.: 51505837
Rupture-proof pH sensor based on IsFET technology.
TopHit H
CPS 401 Short response time, very high resistance to alternating
temperature cycles, sterilisable, almost no acid or
alkaline errors
Technical Information:
TI 283C/07/en, Order No.: 51506685
Rinse connection adapter CPR 40 for the transport of cleaning agents for use with
retractable assemblies.
Technical Information TI 342C/07/en, Order No. 51510059
CYR 10 / CYR 20 ChemoClean Spray Cleaning System for the transport of cleaning
agents or acids for use with retractable assemblies.
Technical Information TI 046C/07/en, Order No. 50014223
The service adapter aids communication between Endress+Hauser transmitters and
the PC using the service interface. You can use it to load new firmware and to save/write
customer data (using a PC with the Windows 95/98 or Windows NT operating system).
• CPK 1: Version with pilot wire and additional outer screen, sheathed in PVC, dia.
7.2 mm. Extension with cable CYK 71 possible, see table "Measuring cable as yard
goods".
• CPK 9: For pH/redox electrodes with integrated temperature sensor and TOP68 plug-
in head (version ESA, ESS). Extension with cable CYK 71 possible, see table "Measu-
ring cable as yard goods".
• CPK 12: For IsFET pH sensors and pH/redox electrodes with integrated temperature
sensor and TOP68 plug-in head. Extension with cable CYK 12 possible, see table
"Measuring cable as yard goods".
• Junction box VBM: Junction box for extending measuring cable connection between
electrode and transmitter. Two screw unions for e.g. combination electrode.
Material: aluminium casting, ingress protection IP 65. Order No.50003987
• Junction box VBA: Junction box for extending measuring cable connection between
electrode and transmitter. Four screw unions for e.g. separate reference electrode.
Material: aluminium casting, ingress protection IP 65. Order No.50003987
Properties
Mycom S CPM 153
Applications
• General process engineering
• Industrial wastewater
• Detoxification (cyanide,
chrome)
• Neutralisation
• General process engineering
• Ultra-pure water
• Boiler feed water
• Detoxification (cyanide)
• General process engineering
• Food processing
• Water treatment
• General process engineering
• Food, pharmaceutical
applications
• Water treatment
• Biotechnology
