Mycom S CPM 153
#
!
135042-0001-4B
Stromausgang / current out / Hart
Glaselektrode / glass electrode
PH REF PA 12 13 11 S PH REF PA 12 13 11 S
Kanal / channel 1 Kanal / channel 2
pH / mV
Koax / coax
REF
PA braun / brown
11 grün / green
12
gelb / yellow
13
weiß / white
Pt100 / Pt1000
Endress+Hauser
Warning!
A mains disconnecting device must be installed near the instrument and must be
identified as the mains disconnection device for the Mycom S CPM 153
(see EN 61010-1).
Note!
Connect unused signal wires from input and output lines to the internal PE rail of the
CPM 153.
4.1.2 Connection sticker
Connections in the connection compartment
CPM153
zusammengehörige
Klemmen /
combined clamps
IsFET
DRN SRC REF PA 12 13 11 S DRN SRC REF PA 12 13 11 S
Kanal / channel 1 Kanal / channel 2
DRN
rot / red
SRC
Koax / coax
REF
PA
braun / brown
11 grün / green
12 ( gelb / yellow )
13
weiß / white
Pt1000
Fig. 7: Connection compartment sticker (you will find it in the connection compartment of the transmitter)
DRN = Drain
SCR = Source
REF = Reference
EX
F
F L N
Kontakte, Best.-Variante /
-..1.. -..2.. -..3..
+
51 54 44 51 54 21
52 55 45 52 55 22 52 55
-
4 Electrical connection
non EX
contacts, order code.
-..4.. -..5..
+ + +
51 54 21 51 23 21 51 23 21
22 52 24 22 52 24
- - -
+ +
22
- -
