6 Start-up
CODE
T13
T14
T15
T16
T17
T18
28
DISPLAY
Hold
off
on
Hold
Hold
Hold
off
on
Hold
Temp.sensor
Pt100
Pt1000
NTC30k
Hold
Relay funct.
Select
CHOICE
(default = bold)
off
on
ATC K1
ATC K2
MTC
MTC+Temp
025.0°C
off
on
Pt 100
Pt 1000
NTC 30k
NAMUR
off
Relay 1:
free
Relay 2:
free
Mycom S CPM 153
INFO
Temperature measurement K1
(only for redox)
Select temperature compensation K2
(only pH, two circuit)
Temperature value K2
(only for pH, two circuit and selection of
MTC or MTC+Temp. in Field T14)
Temperature measurement K2
(only for redox, two circuit)
Select temperature sensor
Contact functions
Depending on the equipment available,
you can assign the function of up to 5
relays here. The relays 1 and 2 will be assi-
gned to an activated NAMUR
function and won't be available for other
functions (compare page 14).
Selection:
Free / Controller / LC / CCW / CCC
Controller: Controller control using relay
LC: Limit contactor function
CCW: ChemoClean water. Water supply for
the ChemoClean function.
CCC: ChemoClean Cleaner. Cleaner sup-
ply for the ChemoClean function.
(Together, CCC and CCW form the
"ChemoClean" function. You can find infor-
mation on ChemoClean on page 72 )
