Mycom S CPM 153
Endress+Hauser
CODE CHOICE
(default = bold)
C1 Electrode 1
Electrode 2
shared
Abort calibration
CA Calibration with manual buf-
fer
(with fixed buffer / automatic
buffer recognition)
CAB1 025.0 °C
(–20.0 ... +150.0 °C)
CAB2 025.0 °C
(–20.0 ... +150.0 °C)
CAB3 / CAB7 Immerse:
pH electrode in buffer 1
CAB4 / CAB8 Temperature 1: 25.0 °C
07.00
(pH –2.00 ... +16.00)
CAB5 / CAB9 Time: 10 s
pH 1:
mV 1:
°C:
CAB6 / CAB10 Invalid calibration value
CAB11 / CAB13 Zero point
Good
Slope
Good
CAB12 / CAB14 Electrode status K1 good
CAB15
Accept
Reject
Recalibrate
CAB16 Electrode in medium?
INFO
Selection for calibration
(only two-circuit)
Select electrode 1 or 2, and then run through calibra-
tion for each individual electrode.
Note in display
Display of the type of on-site calibration selected in the
calibration settings.
Enter temperature,
(only if "Calibrate with MTC" is selected)
Confirm by pressing
Enter buffer temperature
(only if "Calibrate with MTC" is selected)
Confirm by pressing
Handling instructions
Immerse the electrode in buffer 1 / 2.
Confirm by pressing
Enter pH value of buffer 1 / 2
(only with manual buffer)
Confirm by pressing
MTC Checks the stability of the calibration
7.00 Wait until the pH measurement is stable:
0 Time does not count down,
25.0 pH value no longer flashes,
Display "Measured value stable"
Confirm by pressing
Note in display:
If an error is present (e.g. incorrect buffer used), this
message is displayed.
07.00 Note in display:
Info on electrode 1 / 2.
59.00 Data on the zero point, slope and calibration quality.
Note in display:
Electrode status circuit 1 / 2:
There are three status messages for the electrode sta-
tus: "good", "OK.", "bad". If the status is displayed "bad",
electrode replacement is recommended to ensure the
quality of the pH measurement.
F
End of calibration
Accept: Pressing
Reject: The data is not accepted and the device has
not been recalibrated.
Recalibrate: The data is rejected and the device is
recalibrated.
Note in display:
If the electrode is back in the medium, so that
measurement can take place?
6 Start-up
F
F
F
F
F
accepts the new calibration data.
