6 Start-up
!
36
CODE CHOICE
(default = bold)
linear:
EAA1 0/4 mA: 02.00 pH
/ 000.0°C / -0500 mV
20 mA: 12.00 pH
/ 100.0°C / 0500 mV
EAA2 Linear characteristic active.
Table:
EAB1 02
(2 ... 10)
EAB2 pH/Redox/°C/: 000.0
mA: 04.00
EAB3 OK
Delete element(s)
EAB4 pH/Redox/°C/: 000.0
mA: 04.00
EAB5 Valid table
EAB6 Table active
Note!
The controller function "continous controller" can only be assigned to the current
output 2.
One circuit instrument
Current output1 Current output2
(Terminals 31 +, 32 –) (Terminals 33 +, 34 –)
pH/Redox pH/Redox
Temperature Temperature
continous controller
• 2-circuit device: There are two possibilities to put the difference between two pH
values on the current outputs:
– Delta pH as value on current output
If the current outputs are only defined via positive delta pH values, the negative
differences are output as value (see table column 1).
INFO
Entry of the upper and lower measured value limits
The maximum measured value range is
–2 ... +16 pH.
The minimum distance from the upper to the lower
measured value limit is 2 pH units.
(Example.: 0/4 mA: pH 7 and 20 mA: pH 9)
Note in display:
The linear characteristic is activated after confirmation
by pressing "E". Cancel by pressing "PARAM".
Entry of the number of support points (value pairs)
Value pair entry
pH/Redox/°C - mA (number of required value pairs =
number of support points desired in Field EAB1).
Selection:
Are the value pairs OK or do you want to delete
elements?
Delete:
Select the row to be deleted, delete with
confirm by pressing "E".
Note in display (no entry)
Table status If invalid, then back to EAB4.
Note in display:
The table is active after confirmation by pressing "E".
Cancel by pressing "PARAM".
Two circuit instrument
Current output1
(Terminals 31 +, 32 –)
pH/redox circuit 1
pH/redox circuit 2
Temperature circuit 1
Temperature circuit 2
Mycom S CPM 153
T
and
Current output2
(Terminals 33 +, 34 –)
pH/redox circuit 1 or 2
Temperature circuit 1
or 2
Delta pH
continous controller
