Mycom S CPM 153
110
Endress+Hauser
8.4
Installation and removal of parts
Please observe the danger instructions in Chap. 8.3.
The position designations relate to the spare parts list on page 103.
8.4.1
Device view
60
50
ƒig. 29:
Interior view of the transmitter Mycom S
Remarks:
A: The figure shows the non-Ex fuse.
B: Slot for DAT memory module
10: Terminal module
30: Supply module
50: Controller module
60: pH input module
70: Relay module
80: Terminal set pH input
100: Partition plate (not shown in figure)
110: Housing cover
120: Housing bottom
70
100
B
10
8 Troubleshooting
30
A
120
105
