Mycom S CPM 153
Digital inputs
Output signal
Current outputs
Auxiliary voltage output
(for digital inputs
E1-E3)
Interface to
CPG 30 / 300
Limit value and alarm
functions
Controller
Endress+Hauser
Input voltage
Internal resistance
1
: acc. to IEC 746-1, under nominal operating conditions
10.2

Output parameters

pH, redox, temperature
Current range
Error current
1
Measured error
Output distribution, settable
active current output (only non-Ex): Load
passive current output: Input voltage range
1
: acc. to IEC 746-1, under nominal operating conditions
Voltage
Output current
Power supply: Output voltage
Output current
Communication
Setpoint adjustments
Hysteresis for switch contacts
Error delay
Function (selectable):
Controller behaviour
Control gain K
R
Integral action time T
n
Derivative action time T
v
10 Technical data
10 ... 50 V
= 5 k Ω
R
i
0 / 4 ... 20 mA
2.4 mA or 22 mA
max. 0.2% of current range
maximum
pH: 1.8 ... 18 pH
Redox: 300 ... 3000 mV
Temperature: 17 ... 170°C
max. 600 Ω
6 ... 30 V
15 V DC
max. 50 mA
11.5 ... 18 V
max. 60 mA
RS 485
pH –2.00 ... 16.00
pH: 0.1 ... 18
Redox absolute: 10 ... 100 mV
Redox relative: 1 ... 3000%
0 ... 6000 s
Pulse-length controller (PWM)
Pulse-frequency controller (PFM)
Three-point step controller (3-PS)
Analogue (via current output)
P / PI / PID
0.01 ... 20.00
0.0 ... 999.9 min
0.0 ... 999.9 min
111
