Mycom S CPM 153
Endress+Hauser
CODE CHOICE
(default = bold)
JB4 °C:
000.0
005.0
...
JB5 OK
Delete element(s)
JB6 °C:
000.0
005.0
...
JB7 Valid table
Cal. settings:
JC1
MTC
ATC 1
ATC 2
JC2
5.00 mV/pH
(5.00 ... 57.00 mV/pH)
JC3 pH 1.30
(0.05 ... 2.00 pH)
JC6 off
on
INFO
pH: Value pair entry
04.00 Enter temperature and pH/Redox (number of required
04.05 value pairs = number of support points desired in
... field JB3).
Selection:
Are the value pairs OK or do you want
to delete any of them?
pH:
Delete:
Select the row to be deleted, delete it with
04.00
04.05 confirm this with "E".
...
Note in display:
The table is active after confirmation by pressing "E".
Cancel by pressing "PARAM".
Select the temperature compensation for the
calibration
ATC = automatic temp. comp.
!
MTC = manual temp. comp.
Note!
The setting is only active during calibration. In meas-
urement mode, the setting selected in GAA1 is valid.
Entry of difference to slope for alarm function
If the entered slope difference is exceeded, an alarm
(error no. 032 / E035) can be triggered (error activation
in field H5).
Entry of pH value zero point deviation
for the alarm function
If the zero point deviates from the reference zero point
by the value entered here, an alarm (Error no. 033) can
be triggered (error activation in field H5).
SCC (Sensor Condition Check)
This function monitors the electrode status or the
degree of electrode ageing. Possible status mes-
sages: "Electrode OK", "Low wear" or "Replace elec-
trode". The electrode status is updated after each cali-
bration. When the "Replace electrode" message
!
appears, an error message may be displayed.
Note!
This function is only available for glass electrodes. If
you are using a glass electrode and an IsFET sensor,
you can use the SCC function without restriction.
However, the SCC function only monitors the glass
electrodes.
6 Start-up
T
and
47
