6 Start-up
⇒
PARAM
⇒
PARAM
68
To enter the menu, proceed as follows:
CODE CHOICE
(default = bold)
P1 Limit switch 1
Limit switch 2
Limit switch 3
Limit switch 4
Limit switch 5
Limit switch 1 / 2 / 3 / 4 / 5:
PA1 / PB1 / Function
PC1 / PD1 / Assignment
PE1 On point:
Off point:
PA2 / PB2 / On delay:
PC2 / PD2 / Off delay:
PE2 Alarm
threshold:
6.5.14 Set up 2 - Controller quick adjustment
In this menu you can adjust the controller setpoint.
To enter the menu, proceed as follows:
⇒
INFO
Selection
of the limit switch which you wish to configure. There are
five limit switches available.
off Limit switch configuration:
pH/Redox Function: activation of function as limit switch
pH 16.00 Assignment: Selection of the measured value which shall
(1500 mV/ valid for the limit value. Selection: pH/redox, tempera-
100%/150°C) ture, Delta (only if operating mode = redundancy)
pH 16.00 On point: Entry of the value at which the limit value
(1500 mV/ function is activated.
100%/150°C) Off point: Entry of the value at which the limit value
function is deactivated.
(Settable range: pH –2.00 ... 16.00 /
–1500 mV ... +1500 mV / 0 ... 100% / –50 ... +150°C)
0000 s Limit switch configuration:
0000 s On delay: Entry of the switch-on delay
pH 16.00 (Range 0 ... 2000 s)
(150°C) Off delay: Entry of the switch-off delay
(Range 0 ... 2000 s)
Alarm threshold: Entry of the value (alarm threshold) at
which the fault signalling contact switches.
⇒
