Accessories

Parawin
The Parawin tool provides you with a graphic PC operating program for configuring your
measuring point at the PC using a simple and self-explanatory menu structure. Write the
configuration to the DAT module using the RS232 interface on the PC. The module can
then be plugged into the transmitter. You can switch the language via software.
The offline configuration system consists of a DAT module, the software and a DAT
interface (RS 232). Required operating sytem: Windows NT/95/98/2000.
Order No.: 51507133 (only Mycom S)
Order No.: 51507563 (TopCal S, TopClean S / Mycom S)
The DAT module is a memory device (EEPROM) which can be easily plugged into the
connection compartment of the transmitter. Using the DAT module, you can
• save complete settings, logbooks and the data loggers of the CPM 153 and
• copy the complete settings to other CPM 153 measuring transmitters which have
identical hardware functionality.
This considerably reduces the effort to install or service several measuring points. Order
No.: 51507175
Type
The immersion assembly with flange and bayonet
DipFit P
CPA 140 system allows rapid electrode installation and removal,
integration of ChemoClean
without conversion.
Technical Information:
TI 178C/07/en, Order No.: 50088968
Flow assembly for up to three electrodes, using a
FlowFit P
CPA 240 siphon-like construction, electrodes are kept wet even if
the flow is interrupted.
Technical Information:
TI 178C/07/en, Order No.: 50088970
Retractable assembly for manual or pneumatic
CleanFit
CPA 471 / operation. Cleaning and calibrating the electrode is
472 / 473 / possible in process.
474 / 475 CPA 475: 3A approval, EHEDG.
Technical Information:
CPA 471: TI 217C/07/en, Order No.: 51502596
CPA 472: TI 223C/07/en, Order No.: 51502645
CPA 473: TI 344C/07/en, Order No.: 51510923
CPA 474: TI 345C/07/en, Order No.: 51510925
CPA 475: TI 240C/07/en, Order No.: 51505599
Properties
®
electrode cleaning possible
9 Accessories
Applications
• Open and closed containers
and tanks
• Channel
• Pipelines
• General process engineering
(471, 472, 473, 474)
• Food, pharmaceutical
applications (475)
• Biotechnology (475)
