PRODUCT LINE DESCRIPTION
The MSA left/RIGHT electronic product range is designed to improve safety and working conditions in noisy environments. It consists of diff erent versions such as
FM Radio, CutOff and Dual. This user information is applicable for all versions. Please refer to the section applicable for your version for handling instructions. To
ensure you get the best comfort, fi t and function out of the product it is important that you read the instructions carefully and save them for future reference.
Please refer to the attenuation table for further details on noise reduction. Make sure you have selected the correct product for your application.
APPROVALS
The product meets the Basic Safety Requirements as laid out in Annex II of the European Community Directive 89/686/EEC and the requirements of the EMC
directive 89/336/EEC. The product is tested and approved by Finnish Institute of Occupational Health (FIOH), Topeliuksenkatu 41aA, FIN-00250 Helsinki, Finland
(Notifi ed Body number 0403) and CE marked according to the relevant parts of EN352-1:2002, EN352-3:2002,
EN352-4:2001/A1:2005, EN352-6:2002 and EN352-8:2008.
GENERAL FITTING INSTRUCTIONS
Before following the fi tting instructions below, brush excess hair aside and remove any ear jewellery that could aff ect acoustic seal. The cushions should form a snug
fi t against the head with no interference of the seal by any objects e.g. respirator headbands or spectacles arms, and that the cups completely enclose the ears.
Headband version (Illustration A)
A 1:Make sure to put the headband the right way round. The inside of the headband is marked with a letter L on the left hand side and a letter R on the right
hand side. Ensure that the headband is positioned correctly.
A 2: With the headband over the head, adjust the height of the cups by sliding them up or down so they completely enclose the ears.
Helmet attachment (Illustration B)
B 1: Left and Right cups. The cups are designed to be used either on the left hand side or on the right hand side of the helmet. The cup marked with a letter L
must be put on the left hand side of the helmet and the cup marked with a letter R must be put on the right hand side of the helmet. Make sure to put them the
right way round.
B 2-3: Fitting the cups. Pull the ear cup down to the bottom of the yolk and lift the blade until the spring clicks up (B2). Push the attachment blade fi rmly into
the slot on the side of the helmet until it clicks into place (B3). Release the head harness from the rear of the helmet and place the lead from the cups above the
harness' attachment and replace the harness. Make sure the lead is not tangled.
B 4: Working Position. Adjust the cups until they are comfortable. Make sure that the cushions seal tightly around the ears.
NOTE! In noisy environments, the ear-muff s must be worn in the working position at all times.
B 5: Stand-by position. Pull the ear-muff away from the ear until it locks into the stand-by position.
B 6: Parking Position. First lift the cups to the stand-by position, and then rotate them up to the next fi xed position. In this position, the cushion does not get
damaged or dirty and the cups can dry out on the inside.
NOTE: Do not press the cups onto the helmet shell as this will lock the spring in the ear-muff arm, and damage the attachment slots on the
side of the helmet.
B 7: Storage Position. When the helmet is not in use, lower the ear-muff s and press them inward.
Battery replacement (Illustration E)
The product must be equipped with two standard alkaline batteries, 1.5 V AA/LR6. The use of rechargeable batteries such as NiMH 1.2 V or NiCd 1.2 V will
signifi cantly reduce the operating time. The battery compartment is located in the left cup. To install new batteries, remove the lid (E1) and insert the batteries.
Make sure that the + and – poles are correctly aligned (E2). Replace the lid.
The product should be turned off during battery replacement.
HOW TO OPERATE THE PRODUCT
HANDLING INSTRUCTIONS APPLICABLE FOR THE FM-RADIO
PRODUCT CHARACTERISTICS
These ear-muff s are equipped with an integrated FM radio receiver which operates over the FM frequency band.
FUNCTION KEYS (Illustration G)
On/off (O) (G1)
Switch on the electronics by pressing the key (O). To switch off , press the same key (O) and hold for 2 seconds.
Volume adjustment, (O) (G1)
Adjust the volume by pressing shortly on (O). When switched on, the volume starts at the same setting
as when it was last switched off . The volume has four fi xed settings. When the highest volume setting has been reached, pressing the key again will start the
volume from the lowest setting.
Setting the radio station, (+) (–) (G2)
The FM Radio frequency band is 88–108 MHz. Station tuning is automatic. Pressing the desired directional key down (–) or up (+) will tune the radio to the next
station and then stop. A short beep will be heard whenever a key is pressed. A long beep is heard at each end of the frequency band. The FM Radio starts at the
latest used station. This memory is erased when the batteries are replaced.
Frequency Hopping
To hop to the higher end of the frequency band press the (+) and (O) keys simultaneously, and to hop to the lower end press the (–) and (O) keys simultaneously.
Audio Input (AUX) (G3)
The product has one input, a 3.5-mm stereo socket, for connecting an external audio source such as a communication radio, hunting radio, mobile phone,
CD player, radio, etc. If there is a call on the audio input, the FM radio is automatically muted and remains muted until around 5 seconds after the end of the
call. If there is a pause in the call lasting more than 5 seconds, the FM radio setting function will automatically be restored. If the audio signal does not exceed
1767 mVrms (rms = root mean square of signal strength), the sound level inside the hearing protector will not exceed 82 dB(A).
