4.12 Replacing the Motherboard Assembly
For ILOM 3.0 CLI: Restore OpenBoot PROM variables per Chapter 10,
■
"Backing Up and Restoring ILOM Configuration," from the Oracle Integrated
Lights Out Manager (ILOM) 3.0 CLI Procedure Guide (821-1611) available at:
//docs.oracle.com/cd/E19860-01/index.html. Use the same passphrase used
during the back up to restore the OpenBoot PROM variables.
For ILOM 2.0: Use the data collected during Step 1 of
■
Motherboard Assembly" on page 114
variables with the OpenBoot PROM setenv command.
Return the server to operation. See
5.
Operation".
4.12

Replacing the Motherboard Assembly

This section describes how to remove and install the motherboard assembly.
Caution -
Caution -
variable settings for ILOM. If you are replacing a motherboard, you must move the SCC
module from the old motherboard to the new one. You must also backup OpenBoot PROM
variables for restoring after motherboard replacement.

Remove the Motherboard Assembly

1. Back up OpenBoot PROM variables with one of the following procedures:
For ILOM 3.0 Web Interface: Back up per Chapter 10, "Backing Up and Restoring ILOM
■
Configuration," from the Oracle Integrated Lights Out Manager (ILOM) 3.0 Web Interface
Procedure Guide (820-0052) available at:
index.html. Use a passphrase to backup the OpenBoot PROM variables.
For ILOM 3.0 CLI: Back up per Chapter 10, "Backing Up and Restoring ILOM
■
Configuration," from the Oracle Integrated Lights Out Manager (ILOM) 3.0 CLI Procedure
Guide (821-1611) available at: http://docs.oracle.com/cd/E19860-01/index.html. Use
a passphrase to backup the OpenBoot PROM variables.
For ILOM 2.0: The ILOM Back up/Restore feature is absent. Record output from the
■
OpenBoot PROM printenv command or the Oracle Solaris eeprom command for use after
motherboard replacement.
114 Sun Netra T5440 Server • September 2015
This procedure must be performed by a certified Sun Oracle Service Technician only.
The SCC module contains system host ID, MAC addresses, and configuration
to restore the OpenBoot PROM
Chapter 6, "Returning the Server to
http://docs.oracle.com/cd/E19860-01/
http:
"Remove the
