80404"Rqtv"Gpcdng"
On this page, you can enable the port for the MAC VLAN feature. Only the port is enabled, can the
configured MAC VLAN take effect.
Choose the menu XNCP→OCE"XNCP→Rqtv"Gpcdng to load the following page.
Select your desired port for VLAN Mapping function. All the ports are disabled for VLAN Mapping
function by default.
Configuration Procedure:
Uvgr" Qrgtcvkqp"
1 Set the link type for
port.
2 Create VLAN.
3 Create MAC VLAN.
4 Select your desired
ports for MAC VLAN
feature.
805" Rtqvqeqn"XNCP"
Protocol VLAN is another way to classify VLANs basing on network protocol. Protocol VLANs can
be sorted by IP, IPX, DECnet, AppleTalk, Banyan and so on. Through the Protocol VLANs, the
broadcast domain can span over multiple switches and the Host can change its physical position
in the network with its VLAN member role always effective. By creating Protocol VLANs, the
network administrator can manage the network clients basing on their actual applications and
services effectively.
This switch can classify VLANs basing on the common protocol types listed in the following table.
Please create the Protocol VLAN to your actual need.
Figure 6-8 Enable MAC VLAN for Port
Fguetkrvkqp"
Required. On the XNCP→:2403S" XNCP→Rqtv" Eqphki page, set
the link type for the port basing on its connected device.
Required. On the XNCP→:2403S" XNCP→XNCP" Eqphki page,
click the Etgcvg button to create a VLAN. Enter the VLAN ID and
the description for the VLAN. Meanwhile, specify its member ports.
Required. On the XNCP→OCE"XNCP page, create the MAC VLAN.
For the device in a MAC VLAN, it's required to set its connected
port of switch to be a member of this VLAN so as to ensure the
normal communication.
Required. On the XNCP→OCE" XNCP→Rqtv" Gpcdng page, select
and enable the desired ports for MAC VLAN feature.
Protocol Type Type value
ARP 0x0806
IP 0x0800
MPLS 0x8847/0x8848
67
