320503" KRx6"Ownvkecuv"Vcdng"
On this page you can view the information of the multicast groups already on the switch. Multicast
IP addresses range from 224.0.0.0 to 239.255.255.255. The range for receivers to join is from
224.0.1.0 to 239.255.255.255.
Choose the menu Ownvkecuv→Ownvkecuv"Vcdng→KRx6"Ownvkecuv"Vcdng to load the following page.
The following entries are displayed on this screen:
Ugctej"Qrvkqp"
"
Ownvkecuv"KR<"
XNCP"KF<"
Rqtv<"
V{rg<"
Ownvkecuv"KR"Vcdng"
"
Ownvkecuv"KR<"
XNCP"KF<"
Hqtyctf"Rqtv<"
V{rg<"
320504" KRx8"Ownvkecuv"Vcdng"
This page displays the IPv6 multicast groups already on the switch.
Figure 10-21 IPv4 Multicast Table
Enter the multicast IP address the desired entry must carry.
Enter the VLAN ID the desired entry must carry.
Select the port number the desired entry must carry.
Select the type the desired entry must carry.
Cnn: Displays all multicast IP entries.

Uvcvke: Displays all static multicast IP entries.

F{pcoke: Displays all dynamic multicast IP entries.

Displays multicast IP address.
Displays the VLAN ID of the multicast group.
Displays the forward port of the multicast group.
Displays the type of the multicast IP.
163
