SuperTrak EX Series User Manual
Global LED Display
Global LEDs glow in response to Logical Drive status.
LED
Dark
Green
Amber
Red
When a Global LED glows amber or red, you must diagnose and resolve the
logical drive problem in the SuperBuild BIOS or in WebPAM PRO.
See "Chapter 8: Troubleshooting" on page 257.
Logical Drive Status
System off
Normal
Logical Drive Critical
Logical Drive Offline
294
