SuperTrak EX Series User Manual

Installing the BBU

To install the BBU onto your SuperTrak EX Controller card in the Host PC:
1. Power down your system.
2. Remove the cover of your system.
3. Detach the SAS multi-lane cables from the SuperTrak EX Controller card.
4. Remove the screw holding the SuperTrak EX Controller card to the system
case.
5. Gently pull the SuperTrak EX Controller card out of the PCI-Express slot and
remove it from the system.
6. Place the SuperTrak EX Controller card on an anti-static surface with the
connectors facing up.
7. Attach the BBU module connector on the Battery Assembly to the BBU
module connector on the SuperTrak EX Controller card. See Figure 2.
The electronic components on the SuperTrak EX Controller cards
are sensitive to damage from Electro-Static Discharge (ESD).
Observe appropriate precautions at all times when handling the
SuperTrak card or its subassemblies.
Before installing the BBU onto SuperTrak EX Controller card,
backup any important or useful data. Failure to follow this
accepted PC practice could result in data loss.
Warning
Warning
288
