Direct LED Display

Direct LEDs, glow and blink in response to the SuperTrak's firmware status.
Fault
LED
OFF
ON
OFF
ON
OFF
ON
ON
Blink
OFF
Blink
Blink
Blink
For more information, see:
• "Managing Physical Drives" on page 87 or page 146
• "Managing Disk Arrays" on page 89 or page 150
• "Managing Logical Drives" on page 92 or page 166
• "Managing Spare Drives" on page 97 or page 172

Aggregate LED Display

Aggregate LEDs glow or blink in response to Storage Device (physical drive)
activity.
LED
OFF
ON
Activity
LED
OFF No physical drive
ON Unconfigured physical drive
ON Configured physical drive – Status OK
ON Configured physical drive – Status Not OK
ON Global spare drive – Status OK
ON Physical drive – Status Dead
ON Stale condition
ON Rebuilding
Blink Activity
ON Locate physical drive
ON Locate logical drive
ON Locate disk array
Storage Device Status
No activity
Storage device (physical drive) activity
