SuperTrak EX Series User Manual
4. Click the Logical Drives
5. Click the Logical Drive
To specify an Alias or set the Read and Write Policies, click the Settings tab.
Logical Drive Status
See "Logical Drive Status" on page 166.
Logical Drive Synchronization
Synchronization is an automatic procedure applied to logical drives when they
are created. Yes means the logical drive was synchronized.
Adjustable Items
• Alias – Optional
• Read Policy
• Write Policy
See "Changing Logical Drive Settings" on page 168.

Viewing Logical Drive Statistics

To view information for a single logical drive:
1. Click the Subsystem
2. Click the Disk Arrays
3. Click the Disk Array
4. Click the Logical Drives
5. Click the Logical Drive
6. From the dropdown menu on the Information tab, choose Statistics.

Changing Logical Drive Settings

To make logical drive settings:
1. Click the Subsystem
2. Click the Disk Arrays
3. Click the Disk Array
4. Click the Logical Drives
5. Click the Logical Drive
6. Click the Settings tab in Management View.
icon
icon.
icon in Tree View.
icon.
icon.
icon
icon.
icon in Tree View.
icon.
icon.
icon
icon.
168
