SuperTrak EX Series User Manual
Figure 1. SuperTrak EX4650 card
Figure 2. SuperTrak EX8650 card
SuperSwap connector
SuperSwap connector
Activity and
Fault LED Pins
BBU module
connector
Activity and
Fault LED Pins
BBU module
connector
10
Global and
Aggregate
LED Pins
SAS Ports
Ch1-4
Global and
Aggregate
LED Pins
SAS Ports
Ch5-8
Ch1-4
