SuperTrak EX Series User Manual
You can also view events by clicking the Subsystems
clicking the Event tab in Management View.

Saving the Event Frame

This function saves a copy of the events from the Event Frame as a text file on
the Host PC's hard drive.
To save the event log:
1. In the Header, click Show Event Frame.
2. In the Event Frame, click the Save Events button.
3. In the File Download dialog box, click the Save button.
4. In the Save dialog box, name the file, navigate to the folder where you want
to save the log file, and click the Save button.
The event log is saved as a text file on the Host PC's hard drive.

Deleting the Event Frame

This function deletes the events from the Event Frame and from the WebPAM
PRO database. Deleting the events from this point does not affect events
physically stored in the HBA's or Subsystem's RAM or NVRAM.
This function has no effect upon events reported under the Subsystem
Events tab. See "Viewing the Runtime Event Log" on page 130 and "Viewing the
NVRAM Event Log" on page 131.
To clear the event log:
1. In the Header, click Show Event Frame.
2. In the Event Frame, click the Delete Events button.
3. In the Confirmation dialog box, type confirm and click the OK button.

Viewing the Storage Network

The Storage Network consists of all the subsystems and host PCs currently
accessible on your network. Use this function to identify the subsystem or host
PC you want to add.
Subsystems and host PCs already added to WebPAM PRO have a + icon beside
them in Tree View.
114
icon in Tree View, then
icon
