SuperTrak EX Series User Manual
Features
Tested compatibility to coexist
with motherboards that have
integrated IDE controllers
Features LBA support
Supports BIOS Boot
Specification

Specifications

• Port Counts and Connectors
EX4650: 4 internal, one SFF-8087
EX8650: 8 internal, two SFF-8087
EX8654: 4 internal, one SFF-8087; 4 external, one SFF-8088
EX8658: 8 external, two SFF-8088
EX16650: 16 internal, four SFF-8087
• Interface: PCI-Express x8 Slot
• I/O Processor
EX4650: 667 MHz
EX8650: 800 MHz
EX8654, EX8658, EX16650: 1.2 GHz
• Memory (DDR-II)
EX4650: 128 MB
EX8650: 256 MB
EX8654, EX8658, EX16650: 512 MB
• Controller card dimensions (HWD):
EX4650, EX8650, EX8654, EX8658:
2.69 x 6.63 x 0.75 inches (68.3 x 168.3 x 19.0 mm) "Low profile"
EX16650:
4.37 x 6.63 x 0.75 inches (111.0 x 168.3 x 19.0 mm) "Full height"
• Operating temperatures
Without BBU: 32
With BBU: 32
• Operating humidity: 5% to 95% non-condensing
Compatibility
Improves system performance and minimizes
system conflicts for new and existing
installations.
Supports drives greater than 137 GB capacity.
All logical drives attached to the SuperTrak card
appear in the BBS-compliant motherboards
BIOS boot list.
° ° °
to 122 F (0 C to 50
° ° °
to 104 F (0 C to 40
Benefits
°
C)
°
C)
6
