SuperTrak EX Series User Manual

Working with Subsystem/Host Management

Subsystem/Host Management includes the following functions:
• Viewing Subsystem/Host Information (page 120)
• Adding a Subsystem or Host (page 120)
• Deleting a Subsystem or Host (page 121)
• Setting User Privilege (page 122)

Viewing Subsystem/Host Information

To view the Subsystem/Host List:
1. Click the Administrative Tools
2. Click the Subsystem/Host Management
In the Information tab, the following information appears:
• Subsystem/Host IP address
• Management Port IP address
• Health – A green checkmark means OK. A red X indicates a problem
• Model of the RAID controller
• Alias of the RAID controller
• Firmware Version of the RAID controller
• Interface of the RAID controller
• World Wide Number of the RAID controller
If a red X appears under Health, click the Health Information
display a breakdown showing the health of the controller, disk arrays, logical
drives, spare drives, and physical drives.

Adding a Subsystem or Host

To add a subsystem/ or host PC to WebPAM PRO:
1. Log into WebPAM PRO as the Administrator or a Super User.
2. Click the Administrative Tools
3. Click the Subsystem/Host Management
4. Click the Add Subsystem/Host tab in Management View.
icon in Tree View.
icon.
icon in Tree View.
icon.
120
icon to
