SuperTrak EX Series User Manual
Global LED Display
Global LEDs glow in response to Logical Drive status.
LED
Dark
Green
Amber
Red
Direct LED Display
Direct LEDs, glow and blink in response to the SuperTrak's firmware status.
Fault
LED
OFF
ON
OFF
ON
OFF
ON
ON
Blink
OFF
Blink
Blink
Blink
Logical Drive Status
System off
Normal
Logical Drive Critical
Logical Drive Offline
Activity
LED
OFF
No physical drive
ON
Unconfigured physical drive
ON
Configured physical drive – Status OK
ON
Configured physical drive – Status Not OK
ON
Global spare drive – Status OK
ON
Physical drive – Status Dead
ON
Stale condition
ON
Rebuilding
Blink
Activity
ON
Locate physical drive
ON
Locate logical drive
ON
Locate disk array
Firmware Status
