1. Introduction

1
I ntroduction
Thank you for choosing Lightware's MMX4x2 series device. In the first chapter
we would like to introduce the device highlighting the most important features
in the below listed sections:

Description

Î

Compatible Devices

Î

Box Contents

Î
Features
Î
Typical Application
Î
MMX4x2 series – User's Manual
1.1. Description
MMX4x2 series device is a unique mini size matrix switcher. HT200
model has three HDMI inputs and one HDBaseT
input port. It has two independent HDMI outputs. HDMI model has
four HDMI inputs and two independent HDMI outputs. Audio can be
de-embedded from the HDMI signal to a balanced 5-pole Phoenix
(Euroblock) port and external audio signal can be embedded into the
HDMI stream from another 5-pole Phoenix input port. The volume and
gain properties of the audio signal can be modified at both input and
output. The unit is fully 4K/UHD/3D capable and HDCP compliant. The
device has built-in Event Manager tool configurable via the Lightware
Device Controller software. Further control options are served by the
USB, RS-232, IR (in and out) and Ethernet ports.
Model Denomination
4 inputs and 2 outputs Model number
MMX4x2-HT200
Multimedia matrix HDMI and TPS (HDBaseT
1.2. Compatible Devices
The MMX4x2-HT200 matrix is compatible with other Lightware TPS
transmitters, matrix TPS and TPS2 boards, 25G TPS2 boards, as well
as third-party HDBaseT-extenders, displays, but not compatible with
the phased out TPS-90 extenders.
The MMX4x2-HT200 matrix is
compatible with any third-party
HDBaseT
HDBaseT and the HDBaseT Alliance logo are trademarks of the
TM
HDBaseT Alliance.
The List of Compatible Lightware Devices
▪ MX Modular matrix frames - MX-TPS/TPS2-OB
25G Modular matrix frames - 25G-TPS2-OB
▪
compatible TPS
TM
Standalone TPS matrix frames – MMX6x2-HT series
▪
▪ TPS Transmitters:
– HDMI-TPS-TX95/97
– DVI-HDCP-TPS-TX95/97
– UMX-TPS-TX100 series
– WP-UMX-TPS-TX100 series
– SW4-TPS-TX240
– HDMI-TPS-TX200 series
– DVI-HDCP-TPS-TX200 series
– DP-TPS-TX200 series
1.3. Box Contents
) interfaces
TM
MMX4x2 series
matrix
device.
TM Phoenix Combicon
®
5-pole connector (2x)
UTP patch cable
(3 m)
7
12V DC adaptor with Phoenix Combicon
®
interchangeable plugs 3-pole connector
Infrared emitter unit Infrared detector unit
Safety & warranty info,
Quick Start Guide
