- Page 1 User’s Manual MX2-8X8-HDMI20-AUDIO Multimedia Matrix Switcher...
-
Page 2: Important Safety Instructions
MX2-8x8-HDMI20 series – User's Manual Important Safety Instructions Waste Electrical & Electronic Equipment Common Safety Symbols WEEE Class I Apparatus Construction. This marking shown on the product or its literature, This equipment must be used with a mains power system with a Symbol Description indicates that it should not be disposed with other... -
Page 3: Mx2-8X8-Hdmi20 Series – User's Manual
WARNING! Safety-related information which is highly recom- indicated Hardware/Firmware/Software environment: mended to read and keep in every case! Item Version Lightware Device Controller (LDC) software 1.20.0b5 ATTENTION! Useful information to perform a successful procedure; it is recommended to read. Lightware Device Updater (LDU) software 1.5.0b3... -
Page 4: Table Of Contents
5.2. The Layout of the Built-in Web ..........20 8.5.7. Setting the HDCP State ..............49 7.3.7. Mute Specified Output ..............40 8.6. Preset Handling ................49 6. SOFTWARE CONTROL – LIGHTWARE DEVICE CONTROLLER ...21 7.3.8. Unmute Specified Output ..............40 8.6.1. Creating a New Preset ..............49 6.1. Install and Upgrade ..............21 7.3.9. Lock Specified Output .............. - Page 5 MX2-8x8-HDMI20 series – User's Manual 8.8. Video Output Port Settings ............51 11.2. HDCP Management ..............68 8.8.1. Querying the Status of the Output Ports ........51 11.2.1. Protected and Unprotected Content ..........68 8.8.2. Setting the Signal Type (HDMI mode) ..........51 11.2.2. Disable Unnecessary Encryption ..........
-
Page 6: Introduction
Dolby TrueHD, and DTS-HD Master Audio. Each input port has audio connectors for embedding analog audio into the HDMI stream. Thank You for choosing Lightware Matrix Routers. The MX2-8x8-HDMI20-Audio The matrix is compatible with the latest HDMI 2.0 Likewise, the audio connectors next to the output ports can provide is the first Lightware HDMI2.0 standalone matrix switcher that supports... -
Page 7: Typical Applications
Video Source Unique Front-to-Back Cooling Airflow Design 4Kx2K@60Hz 4:4:4 Audio amplifier MX2-8x8-HDMI20-Audio includes a groundbreaking new cooling design with front-to-back airflow. Inside the 4K@60 4:4:4 Signal Routing chassis, the airflow travels along guiding panes assuring that the most warm areas receive ample amount of cooling air volume. -
Page 8: Installation
2. Installation MX2-8x8-HDMI20 series – User's Manual 2.1. Mounting Options INFO: The method is the same when the matrix would be mounted to a wall. The matrix can be mounted in several ways by the supplied two rack ears. -
Page 9: Connecting Steps
DESTINATIONS EDID Health O O U U T T P P U U T T L L O O C C K K MX2-8x8-HDMI20-Audio Presets CTRL RESET Compact HDMI 2.0 Matrix Switcher output port which is located next to the connected HDMI output port. -
Page 10: Product Overview
LCD screen showing the most important settings and parameters in the front panel menu. Jog Dial Control Knob Easy setting and menu navigation by the jog dial control. Keep dial and click while getting feedback on the LCD. USB Control USB connector for local control functions (e.g. Lightware Device Controller software). -
Page 11: Mx2-8X8-Hdmi20-Audio - Rear View
3. Product Overview MX2-8x8-HDMI20 series – User's Manual 3.2. MX2-8x8-HDMI20-Audio - Rear View RS-232 Port The 3-pole Phoenix connector is used for the local RS-232 serial connection. Compatible Plug Type Pin nr. Signal Ground Tx data Rx data Phoenix Combicon series (3.5mm pitch, 3-pole), type: MC 1.5/3-ST-3.5. -
Page 12: Port Diagram
3. Product Overview MX2-8x8-HDMI20 series – User's Manual 3.4. Port Diagram Embedder HDMI Crosspoint 8x8 De-embedder Video HDMI in HDMI out Converter Analog Analog Audio in Audio out Audio Options The outgoing HDMI signal can carry: ▪ The original audio of the HDMI input signal, or the Analog Audio signal coming from the 5-pole Phoenix input port. -
Page 13: Operation
DESTINATIONS 4.2. Front Panel Operations O O U U T T P P U U T T MX2-8x8-HDMI20-Audio L L O O C C K K Compact HDMI 2.0 Matrix Switcher This chapter is about the powering and operating of the device describing the... -
Page 14: Output Lock
ATTENTION! However, the front panel buttons allow to lock only the output ports, the input ports can also be locked by using Lightware C C O O N N T T R R O O L L... -
Page 15: Control Lock
P P R R E E S S E E T T O O U U T T P P U U T T O O U U T T P P U U T T MX2-8x8-HDMI20-Audio MX2-8x8-HDMI20-Audio L L O O C C K K... -
Page 16: Front Panel Lcd Menu Operations
4.3. Front Panel LCD Menu Operations Parameter Selection ATTENTION! The lowest value of the brightness parameter is 1 OUTPUT MODE when setting via the front panel. The setting is available in Lightware blue colored line means the The company logo is displayed... -
Page 17: Input Ports Menu
4. Operation MX2-8x8-HDMI20 series – User's Manual 4.3.2. Input Ports Menu 4.3.3. Output Ports Menu Video Settings Submenu When entering the menu the HDCP When entering the menu the available video output ports are listed. INPUT PORTS available video input ports are The icons display information about the port and the outgoing signal The encryption towards the source can be set as follows: listed. -
Page 18: Edid Menu
4. Operation MX2-8x8-HDMI20 series – User's Manual Video Settings Submenu Audio Submenu Save Submenu Information about the Analog and The EDID of a connected sink can be saved to the User EDID memory Conversion ANALOG VOLUME the Embedded Audio signal are as follows: The outgoing signal can be routed to the outputs with or without... -
Page 19: Presets Menu
4. Operation MX2-8x8-HDMI20 series – User's Manual 4.3.6. Presets Menu The router can store presets and SAVE PRESET the followings are stored in each Button4 slot: Input/output crosspoint state, Button5 muted/unmuted states. Button6 ATTENTION! When factory Button7 default settings are restored, Button8 presets are deleted. -
Page 20: Software Control - Using The Built-In Web
5.2. The Layout of the Built-in Web The built-in web page allows almost the same controlling functions which are available via the Lightware Device Controller. Select a menu item on the left side; the default screen is the Crosspoint menu with Grid view. -
Page 21: Software Control - Lightware Device Controller
Only one updateable instance can Different versions can be Lightware Device Controller (LDC). The software can be installed on a Windows exist for all users installed for all users PC or Mac OS X. The application can be downloaded from www.lightware.com. -
Page 22: Device Discovery Window
The Ethernet tab consists of two lists: ▪ Favorite Devices: You can add any Lightware device that is connected via Ethernet and no need to browse all the available devices. Devices can be added by pressing the Add button or marking the desired device by the symbol in the All Devices list. -
Page 23: Crosspoint Menu
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual 6.3. Crosspoint Menu 6.3.1. Grid View Grid view is a user-friendly graphical interface displaying the crosspoint state of the matrix router. This is an Device Label The Device Discovery window can be opened by clicking easy way to change between the input sources and output sinks. -
Page 24: Tile View
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual Crosspoint Operations Switching For making a connection click on the desired square. If there is no connection between the desired input and output (the square is dark grey), the mouse pointer becomes a hand (link pointer) before the clicking. - Page 25 6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual State Indicators Switching Operations Following icons display different states of the input/output ports/ Take Mode signal: If the Autotake button is outlined with black color Take mode is active.
-
Page 26: Input Port Properties Window
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual 6.3.3. Input Port Properties Window Input Port Legend Click on a port to display its properties; Signal status information and General Tab the most important parameters are displayed. - Page 27 INFO: The first 2x2 bit of the CEC commands contains identification data of the source and destination address. In this case that is The MX2-8x8-HDMI20-Audio is able to send and receive Consumer Tab selector Select the CEC tab for managing CEC commands.
-
Page 28: Output Port Properties Window
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual 6.3.4. Output Port Properties Window Output Port Legend Video settings Click on a port to display its properties. General Tab Passthrough: no signal conversion. General section... - Page 29 Video status and Embedded audio Tab selector Select the CEC tab for managing CEC commands. The MX2-8x8-HDMI20-Audio is able to send and receive Consumer The signal format and the detected parameters are described in ribbon Electronic Control (CEC) commands. This feature is for remote control these sections.
- Page 30 6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual It can occur that the third-party device can receive, but not execute ▪ Audio InfoFrame the command because it is not supported by the product. Check the Vendor Specific Infoframe ▪...
-
Page 31: Presets
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual 6.4. Presets Saving a Preset to an Empty Slot Step 1. Arrange the desired crosspoint connections in Tile view or Grid view. The router can store presets and the followings are stored in each slot: input/output crosspoint state, muted/ Step 2. -
Page 32: Edid Menu
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual 6.5. EDID Menu 6.5.1. Sources and Destinations The EDID memory consists of four parts: Advanced EDID Management can be accessed by selecting the EDID menu. There are two panels: left one contains Source EDIDs, right one contains Destination slots where the EDIDs can be emulated or copied. -
Page 33: Edid Summary Window
EDID file, or uploaded to the User memory. For more details about EDID Editor please visit our selected User memory. website (www.lightware.com) and download the EDID Editor User's Manual. ATTENTION! The imported EDID overwrites the selected memory place even if it is not empty. -
Page 34: Creating An Edid
MX2-8x8-HDMI20 series – User's Manual 6.5.5. Creating an EDID 6.6. Settings Menu Since above mentioned Advanced EDID Editor needs more complex knowledge about EDID, Lightware 6.6.1. Status Tab introduced a wizard-like interface for fast and easy EDID creation. With Easy EDID Creator it is possible to General information about the product is displayed in this tab: create custom EDIDs in four simple steps. -
Page 35: Network Tab
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual 6.6.2. Network Tab 6.6.4. Front Panel Tab Network-related settings are available on the tab. Certain settings in connection with the front panel LCD are available in the LDC as well. -
Page 36: Advanced View
6. Software Control – Lightware Device Controller MX2-8x8-HDMI20 series – User's Manual 6.7. Advanced View Advanced view is the surface for displaying the LW3 protocol tree. Commands and specific parameters (which are not available on the graphical user interface of the LDC) can be run and set by the controlling tools. -
Page 37: Lw2 Programmers' Reference
> Input number in 2 digit ASCII format (01, 02, 10, 12 etc.) commands to ensure the compatibility with other Lightware products. The <out²> Output number in 2 digit ASCII format (01, 02, 10, 12 etc.) supported LW2 commands are described in this chapter. -
Page 38: View The Installed Firmware
Example ATTENTION! The response shows only the active protocol for the interface that was used to send the Command {IS} → {is} command! Response (SL#●0●<MB_DESC>)CrLf (SL# 0 MX2-8X8-HDMI20-AUDIO V11_AAA0)CrLf ← (SL●END)CrLf (SL END) ← Explanation: The matrix reports its motherboard. -
Page 39: Crosspoint Operations
7. LW2 Programmers' Reference MX2-8x8-HDMI20 series – User's Manual 7.3. Crosspoint Operations 7.3.3. Batch Switch Outputs Description: The matrix is able to switch multiple outputs exactly at the same time. To do this, the normal 7.3.1. Switch an Input to an Output switch commands have to be used. -
Page 40: View The Connection Of An Output Port
7. LW2 Programmers' Reference MX2-8x8-HDMI20 series – User's Manual 7.3.4. View the Connection of an Output Port 7.3.6. View Mutes on all Outputs Description: See the connected input port number of an output port. Description: Viewing all outputs’ mute states. Legend: All <Mx>... -
Page 41: Lock Specified Output
7. LW2 Programmers' Reference MX2-8x8-HDMI20 series – User's Manual 7.3.9. Lock Specified Output 7.5. Commands - Quick Summary Description: Lock output <out>. Output’s state cannot be changed Router Status Commands until unlocking. See in Format Example Operation Command section Command {#><out>} →... -
Page 42: Lw3 Programmers' Reference
(Cr, ‘\r’) and line feed (Lf, ‘\n’) pair. It is organized as a tree structure that provides outstanding flexibility and user-friendly handling with ‘nodes’, ‘properties’ and ‘methods’. The Advanced View of the Lightware Device Controller software is the perfect tool for browsing and learning how the LW3 protocol can be used in practice. -
Page 43: Command Types
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.2.3. Command Types 8.2.4. Prefix Summary DEFINITION: The prefix is a 2-character long code that describes the type of the response. GET command The following prefixes are defined in the LW3 protocol: The GET command can be used to get the child nodes, properties and methods of a specific node. -
Page 44: Signature
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.2.7. Signature 8.2.9. Notifications about the Changes of the Properties DEFINITION: The signature is a four-digit-long hexadecimal value that can be optionally placed before When the value of a property is changed and the user is subscribed to the node, which the property belongs every command to keep a command and the corresponding responses together as a group. -
Page 45: System Commands
Î GET /.ProductName complete list in Factory Default Settings section. Í pr /.ProductName=MX2-8X8-HDMI20-AUDIO Command and Response 8.3.2. Setting the Device Label Î CALL•/SYS:factoryDefaults() The device label can be changed to a custom text which is displayed in many windows of the LDC. -
Page 46: Switching And Crosspoint Settings
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.4. Switching and Crosspoint Settings 8.4.4. Multiple Switching The whole crosspoint can be set by sending one command as follows. INFO: The current setting can be queried by using the command. -
Page 47: Video Input Port Settings
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.5. Video Input Port Settings The Most Common Received Port Status Responses INFO: The current setting can be queried by using the command. 8.5.1. Querying the Status of the Source Ports T00AA Unlocked, Command and Response... -
Page 48: Unmuting An Input Port
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.5.3. Unmuting an Input Port Example Î SET /MEDIA/PORTS/VIDEO/I1/CEC.OsdString=Lightware Command and Response Í pw /MEDIA/PORTS/VIDEO/I1/CEC.OsdString=Lightware Î CALL•/MEDIA/XP/VIDEO:unmuteSource(<in>) Í mO•/MEDIA/XP/VIDEO:unmuteSource=OK Step 2 – Call the CEC.send(set_osd) method Command and Response Example Î... -
Page 49: Setting The Hdcp State
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.6. Preset Handling 8.5.6.3. Sending a CEC Command in Hexadecimal Format Command and Response The router can store presets and the followings are stored in each slot: input/output crosspoint state, muted/ unmuted states. -
Page 50: Renaming A Preset
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.6.4. Renaming a Preset 8.7.2.2. Setting the Balance (by a Step Value) Command and Response Command and Response Î CALL•/MEDIA/PORTS/VIDEO/<in>/ANALOGAUDIO:stepBalance(<step_value>) Î CALL•/MEDIA/PRESET:rename(<Old_name>,<New_name>) Í mO•/MEDIA/PRESET:rename= mO•/MEDIA/PORTS/VIDEO/<in>/ANALOGAUDIO:stepBalance=<step_value> Í Example Example Î CALL /MEDIA/PRESET:rename(My_Pres,Your_Pres) Î... -
Page 51: Video Output Port Settings
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.8. Video Output Port Settings 8.8.3. Muting an Output Command and Response 8.8.1. Querying the Status of the Output Ports Î CALL•/MEDIA/XP/VIDEO:muteDestination(<out>) Command and Response Í mO•/MEDIA/XP/VIDEO:muteDestination=OK Î GET•/MEDIA/XP/VIDEO.DestinationPortStatus Example Í... -
Page 52: Setting The Signal Conversion Mode
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.8.7. Setting the Signal Conversion Mode 8.8.9. Setting the HDCP Mode (Output Port) ATTENTION! The signal conversion can be set on the input and output ports as well, but setting the Command and Response desired signal at the output port is recommended. -
Page 53: Sending Cec Commands Towards The Sink
(0-9), and dot (.). Max length: 14 characters. ▪ play/ stop/ pause/ record/ rewind/ fast_forward/ eject Example ▪ skip_forward/ skip_backward 3d_mode ▪ Î SET /MEDIA/PORTS/VIDEO/O1/CEC.OsdString=Lightware ▪ stop_record/ pause_record Í pw /MEDIA/PORTS/VIDEO/O1/CEC.OsdString=Lightware ▪ play_forward/play_reverse Step 2 – Calling the CEC.send(set_osd) Method stop_function ▪... -
Page 54: Audio Output Port Settings
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.9. Audio Output Port Settings 8.9.2.2. Setting the Volume (by Step Value) Command and Response INFO: The current setting can be queried by using the GET command in all cases. Î... -
Page 55: Port Settings
Identifier Parameter description Parameter values Example <prot_mode> The applied protocol of LW2: Lightware Protocol #2 is applied. Î SET /MANAGEMENT/NETWORK.DhcpEnabled=true the RS-232 port LW3: Lightware Protocol #3 is applied. P#2: The additional P#2 protocol is applied. Í pw /MANAGEMENT/NETWORK.DhcpEnabled=true 8.11.3. Static IP Address Settings Example ATTENTION! To set a static IP address set the DhcpEnabled property to false –... -
Page 56: Edid Management
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.12.2. Setting the Emulated EDID 8.11.3.2. Subnet Mask Setting Command and Response Command and Response SET•/MANAGEMENT/NETWORK.StaticNetworkMask=<Net_mask> Î CALL•/EDID:switch(<Source>:<Destination>) Î pw•/MANAGEMENT/NETWORK.StaticNetworkMask=<Net_mask> Í mO•/EDID:switch= Í Example Parameters Î SET /MANAGEMENT/NETWORK.StaticNetworkMask=255.255.0.0 Identifier Parameter description Parameter values <source>... -
Page 57: Lw3 Commands - Quick Summary
7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual 8.13. LW3 Commands – Quick Summary Operation / Path Unlocking an Input Port System Commands 8.5.5 /MEDIA/XP/VIDEO:unlockSource Operation / Path 8.5.6 Sending CEC Commands Towards the Source Querying the Product Name 8.3.1 /.ProductName Sending an OSD String... - Page 58 7. LW3 Programmers’ Reference MX2-8x8-HDMI20 series – User's Manual Video Output Port Settings Operation / Path Setting the Balance (Exact Value) Operation / Path 8.9.2.3 /MEDIA/PORTS/VIDEO/<out>/ANALOGAUDIO.Balance Querying the Status of the Output Ports 8.8.1 Setting the Balance (by Step Value) /MEDIA/XP/VIDEO.DestinationPortStatus 8.9.2.4 /MEDIA/PORTS/VIDEO/<out>/ANALOGAUDIO:stepBalance...
-
Page 59: Firmware Upgrade
Lightware website and shows the 9.2. Short Instructions www.lightware.com. available version. Step 1. Get the firmware pack and the Lightware Device Updater (LDU) About the Firmware Package (LFP File) Î application. Short Instructions Î... -
Page 60: Detailed Instructions
9. Firmware Upgrade MX2-8x8-HDMI20 series – User's Manual ▪ If you do not want to check for updates automatically, uncheck the Check for updates automatically Click on the Extender button on the main screen. option. Step 1. Select the package. If you want to postpone the update, a reminder can be set with different delays from the drop down list. - Page 61 9. Firmware Upgrade MX2-8x8-HDMI20 series – User's Manual Step 2. Select the device. Firmware Components The components of the installed and update firmware version for the selected devices are listed on the following screen. (Update version will be uploaded to the device.) The next step is to select the desired device(s).
- Page 62 9. Firmware Upgrade MX2-8x8-HDMI20 series – User's Manual Step 3. Upgrade the device. A warning window will pop up before upgrading the device: ▪ Do not unplug the power cable and the LAN cable while the upgrade is in progress. Click OK to continue. Click on the Start button to start the upgrade process.
- Page 63 O O U U T T P P U U T T CTRL MX2-8x8-HDMI20-Audio If the upgrade of a device is finished, the log can be opened by the View button on the right. When all the tasks L L O O C C K K RESET Compact HDMI 2.0 Matrix Switcher...
-
Page 64: Troubleshooting
At first, check front panel LEDs and take the necessary steps according to their states. For more active one information about front and rear panel LEDs of the matrix refer to MX2-8x8-HDMI20-Audio - Front View MX2-8x8-HDMI20-Audio - Rear View section. - Page 65 10. Troubleshooting MX2-8x8-HDMI20 series – User's Manual Symptom Root cause Action Refer to Ethernet Incorrect IP address is set Disable DHCP server and set the Audio signal 6.6.2 (direct connect) IP addresses to be in the same Other audio port is Check the audio crosspoint 8.11...
-
Page 66: How To Speed Up The Troubleshooting Process
In the case of Event Manager issue the event file and/or backup file from the Device Controller ▪ software. The more of the above information you can give us the better. Please send these information to the Lightware Support Team (support@lightware.com) to speed up the troubleshooting process. -
Page 67: Technologies
(dynamic EDID emulation). information about additional Detailed Timings, audio capabilities, For example, the Lightware device can be set up to emulate a sink speaker allocation and HDMI capabilities. It is important to know that device, which is connected to one of the outputs. -
Page 68: Hdcp Management
HDCP v2.2 on the input and encrypted with HDCP v1.4 on the output disabled in the Lightware device. If HDCP is disabled, the connected of the Lightware device. A lower level of encryption may be applied source will detect that the sink is not HDCP capable, and turn off... -
Page 69: Pixel Accurate Reclocking
Data2- and Data2+). It’s caused by different wire lengths or slightly signal. Too much noise results in increased jitter. What Kind of Signal Will be on the Output of the Lightware Device? different wire construction (impedance mismatch) in DVI cable. It See below table that summarizes the possible cases: results in jitter. -
Page 70: Appendix
12. Appendix MX2-8x8-HDMI20 series – User's Manual 12.1. Specifications Standard ............ DVI 1.0, HDMI 1.4, HDMI 2.0 Max. video resolution 4096x2160@60Hz at RGB 4:4:4 (up to 600MHz General pixel clock) Compliance ..................CE Audio formats ....all formats in line with HDMI 2.0 standard EMC compliance (emission) ......... -
Page 71: Mechanical Drawings
12. Appendix MX2-8x8-HDMI20 series – User's Manual 12.2. Mechanical Drawings Direction of the Airflow Front View CONTROL TAKE TAKE LOAD LOAD SAVE SAVE LOCK AUTO AUTO PRESET PRESET PRESET PRESET OUTPUT LOCK Rear View ATTENTION! The ventilators are controlled automatically according to the internal temperature of the device and cannot be adjusted manually by the user. -
Page 72: Factory Edid List
12. Appendix MX2-8x8-HDMI20 series – User's Manual 12.4. Factory EDID List Mem. Resolution Type Mem. Resolution Type Mem. Resolution Type Mem. Resolution Type 1280 x 720 @ 50.00 Hz F112 3840 x 2160 @ 30.00 Hz F148 3840 x 2160 @ 60.00 Hz RB, ALL 640 x... -
Page 73: Audio Cable Wiring Guide
Symmetric audio is most often referred to as balanced audio, as opposed to asymmetric, which is referred to as unbalanced audio. Lightware products are usually built with 5-pole Phoenix connectors so we would like to help users assembling their own audio cables. -
Page 74: Further Information
1.4. Product failures from six (6) months to the end of the warranty prog. ref. chapter period will either be repaired or replaced at the discretion of Lightware. If Lightware chooses to replace the product then the replacement will 19-09-2017 New document format Judit be warranted for the remainder of the original unit’s warranty period.
