11. Appendix
Analog Audio Output Port
Audio port connector .................................... 5-pole Phoenix connector
Signal transmission ........................... Balanced and unbalanced audio
Volume.....................................................................................-57 – 0 dB
Control Ports
RS-232 Control
Serial port connector .................................... 3-pole Phoenix connector
Available Baud rates ................................... between 4800 and 115200
Available Data bits ......................................................................... 8 or 9
Available Parity.......................................................... None / Odd / Even
Available Stop bits ...................................................................1 / 1.5 / 2
USB Control
USB connector .............................................................. USB mini B type
USB 2.0 compliance...........................................................................Yes
Infrared Control
Number of IR ports ....................................................... 2 (1x RX, 1x TX)
Connector type ..................................... 3.5mm TRS (approx. 1/8" jack)
Ethernet
Connector type .................................................................. Locking RJ45
Ethernet data rate .............. 10/100Base-T, full duplex with autodetect
Power over Ethernet (PoE) ..............................................Not supported
MMX4x2 series – User's Manual
11.2. Factory Default Settings
Parameter
Video crosspoint settings
O1 (HDMI out 1) - MMX4x2-HDMI
O1 (HDMI out 1) - MMX4x2-HT200
O2 (HDMI out 2) - for both models
Audio crosspoint settings
O1 (HDMI out 1)
O1 (HDMI out 1)
O3 (Audio out)
Video input port settings
TPS mode *
HDCP
Test pattern mode
Test pattern clock source
Test pattern
Video output port settings
Autoselect feature
Autoselect mode
Signal type
HDCP mode
Power 5V mode
Emulated EDID on all four inputs
Analog audio input port settings
Volume
Balance
Gain
Analog audio output port settings
Volume
Balance
Setting/Value
IP address
Subnet mask
I1 (HDMI in 1)
Static gateway
I1 (TPS in 1)
DHCP
I2 (HDMI in 2)
LW2 port number
LW3 port number
A1 (original HDMI
HTTP port number
embedded audio)
TPS Ethernet status
A2 (original HDMI
embedded audio)
A3 (analog audio input)
Control protocol
Baud rate
Auto
Databits
Enabled
Parity
Disabled
Stopbits
480p
Operation mode (Link and Local)
Bar
Command injection port nr. - Local
Command injection port nr. - TPS *
Disabled
Priority detect
Command injection status
Auto
Comm. inj. input port nr. - Local
Auto
Comm. inj. input port nr. - TPS *
Always on
Comm. inj. output port nr. - Local
Factory #47: Universal
Comm. inj. output port nr. - TPS *
HDMI PCM
Unique port names
0.00 dB (100%)
Unique device label
0 (center)
User EDIDs
0.00 dB
Events
IR codes
0.00 dB (100%)
Presets
0 (center)
Unprotected backups
Protected backups
* Only in case of MMX4x2-HT200 model.
Parameter Setting/Value
Network settings
192.168.0.100
255.255.255.0
192.168.0.1
Disabled
10001
6107
80
Enabled
RS-232 settings
LW2
57600
8
No
1
Control
8001
8002
IR port settings
Enabled
9001
9002
9003
9003
Miscellaneous
Cleared
Cleared
Not cleared
Cleared
Cleared
Cleared
Cleared
Not cleared
