8. Firmware Upgrade
Step 4. Finish.
If the upgrade of a device is finished, the log can be opened by the View button on the right When all the tasks
are finished, a window appears. Click OK to close and Next to display the summary page.
Repeat button starts the process again with the selected device(s).
Open logs button opens the temporary folder where the logs can be found.
Export logs by saving the files as a zipped file.
Press Exit to close the program.
If the upgrade failed, the progress bar of the device is changed to red; restart the device(s) and repeat the
process.
MMX4x2 series – User's Manual
8.5. Keeping the Configuration Settings
User can keep all configuration settings and restore to the device after firmware upgrading or can choose to
perform a factory reset – it means all settings will be erased in the device. In case of factory reset you can
save the settings of the device and restore it later. For the detailed information about saved data refer to the
Content of Backup File section.
The following flow chart demonstrates how this function works in the background.
Start Backup
The details about the procedure:
when firmware upgrade starts, the
first step is making a backup of the
settings of the device. The firmware
package checks the backup data and
if it is needed, a conversion is applied
to avoid incompatibility problems
between the firmware versions. If you
do not want to keep configuration
settings, you can set the Factory reset
option enabled.
The instruction in the firmware
package of the device will inform
you about this function availability,
reading it is highly recommended in
every case.
ATTENTION! In specific cases restoring cannot be applied fully and certain settings are not copied back
to the device. If a warning message appears, user can get back the original data from the backup. Logs of
the upgrade procedure contain all backup data, it can be exported at the end of the upgrade procedure. In
case of any question, please contact support@lightware.com.
ATTENTION! In certain cases, the new firmware version requires setting all parameters to set factory
defaults. In this case, the "Factory reset" option is enabled by default and not changeable by the user, see
details in the Firmware Components
ATTENTION! The feature is only supported by LDU version 1.3.0 and above.
Upgrading Factory reset
Conversion/Restore
Flow chart of firmware upgrade
Instructions page in the firmware package
section.
83
End
