7. LW3 Programmers' Reference
7.6.14. Unmute an Output Port
Command format: CALL●/MEDIA/VIDEO/XP:unmuteDestination(<O
Response format: mO●/MEDIA/VIDEO/XP:unmuteDestination
Example:
˃ CALL /MEDIA/VIDEO/XP:unmuteDestination(O1)
˂ mO /MEDIA/VIDEO/XP:unmuteDestination
7.6.15. Lock an Output Port
Command format: CALL●/MEDIA/VIDEO/XP:lockDestination(<O
Response format: mO●/MEDIA/VIDEO/XP:lockDestination
Example:
˃ CALL /MEDIA/VIDEO/XP:lockDestination(O1)
˂ mO /MEDIA/VIDEO/XP:lockDestination
7.6.16. Unlock an OutputPort
Command format: CALL●/MEDIA/VIDEO/XP:unlockDestination(<O
Response format: mO●/MEDIA/VIDEO/XP:unlockDestination
Example:
˃ CALL /MEDIA/VIDEO/XP:unlockDestination(O1)
˂ mO /MEDIA/VIDEO/XP:unlockDestination
7.6.17. HDCP Setting (Input Port)
HDCP capability can be enabled/disabled on the input ports, thus, non-encrypted content can be seen on a
non-HDCP compliant display. See more information in the
Command format: SET●/MEDIA/VIDEO/<I
Response format: pw●/MEDIA/VIDEO/<I
Example:
˃ SET /MEDIA/VIDEO/I2.HdcpEnable=true
˂ pw /MEDIA/VIDEO/I2.HdcpEnable=true
>)
n
>)
n
>)
n
HDCP Management section.
>.HdcpEnable=true|false
n
>.HdcpEnable=true|false
n
MMX4x2 series – User's Manual
7.6.18. HDCP Setting (Output Port)
HDCP capability can be set to Auto/Always on the output ports, thus, non-encrypted content can be
transmitted to a non-HDCP compliant display. See more information in the
Command format: SET●/MEDIA/VIDEO/<O
Response format: pw●/MEDIA/VIDEO/<O
Parameters:
.HdcpModeSetting
HDCP mode
Example:
˃ SET /MEDIA/VIDEO/O1.HdcpModeSetting=0
˂ pw /MEDIA/VIDEO/O1.HdcpModeSetting=0
7.6.19. Test Pattern Generator
The output ports can send a special image towards the sink devices for testing purposes. The setting is
available on output ports with the below-listed parameters.
ATTENTION! The Mode can be set individually on each port, but the Clock source and the Pattern settings
are common on the optical and HDMI output ports (O1 and O2).
Test Pattern Generator Mode Setting:
Command format: SET●/MEDIA/VIDEO/<O
Response format: pw●/MEDIA/VIDEO/<O
Parameters:
.TpgMode

Test pattern generator

The test pattern is not
mode displayed on the output
Example:
˃ SET /MEDIA/VIDEO/O1.TpgMode=2
˂ pw /MEDIA/VIDEO/O1.TpgMode=2
HDCP Management
>.HdcpModeSetting=0|1
n
>.HdcpModeSetting=0|1
n
0 1
Auto Always
>.TpgMode=0|1|2
n
>.TpgMode=0|1|2
n
0 1
Disabled Enabled
The test pattern is
displayed on the output
signal on the output port
60
section.
2
No signal mode
The test pattern is
displayed if there is no
