7.5 Selecting a unit in a stack

Symbol for selection a unit
External operation of a unit
Procedure
2013-02-19
In the standard operating mode, the currently selected unit ist hat
to which the operating panel belongs.
For example, the lowest unit in a stack of 3 is always the „bottom
unit".
For stacked units, any of the operating panels in the stack can be
used to control each unit individually or all units.
NOTICE!
The units in a stack are assigned from the bottom
to top.
The symbol on the operating panel for selecting units shows that
all 3 units are selected for remote access.
NOTICE!
The timer function cannot be operated from
remote!
Units that are under operation of the timer cannot
be accessed by remote!
All units must be switched on using the main switch so that they
can be selected via the control system.
1. Press REMOTE key to select a unit.
Bottom unit is selected.
Multitron Pro - Incubation Shaker
Operation
Page 115 of 185
