Infors HT Multitron Pro Operating Manual page 71

Fig. 38
Fig. 39
Fig. 40
2013-02-19
Label "outside"
The curtain is made of transparent PVC sheeting, 0.75 mm thick.
There are four snap fasteners on the upper front edge of the
incubation chamber to attach the curtain.
The lower edge of the curtain has 8 slits to facilitate handling of the
tray.
The curtain is marked "outside" so that it can be fitted correctly.
The transparent curtain is attached to the upper front edge of the
housing by means of the 4 snap fasteners.
The curtain prevents large amounts of CO
door is opened.
NOTICE!
The safety curtain keeps the CO
incubation chamber:
approx. 60% on opening the door
approx. 40% on pulling out the tray
There are two types of safety curtain:
CO – closed
2
CO + humidification – with 8 circular holes (Ø 45 mm) in the
2
upper section
Multitron Pro - Incubation Shaker
Setup and function
escaping when the
2
gas inside the
2
Page 71 of 185
