Warning symbol
4.4 Serial interface
RS 232, 9-PIN
6
7
8
9
Fig. 22
Alarm contacts
Fig. 23
2013-02-19
The warning symbol lights at any operations. Additionally it lights
when as alarm or error is triggered. The warning symbol supports
the user to operate the incubation shaker properly.
The unit is equipped with an RS 232 serial interface.
PIN assignments
1 + 6
1
1 + 7
2
3
8
4
5
9
NORMAL STATE
ALARM and
POWER FAILURE
RESERVE
RESERVE
Multitron Pro - Incubation Shaker
Setup and function
2
RX (RECEIVE)
3
TX (TRANSMIT)
4
RESERVE
5
GND
Page 57 of 185
