Switching On The Cooling System - Infors HT Multitron Pro Operating Manual

Multitron Pro - Incubation Shaker
Installation and initial operation
Fig. 71
Fig. 72

6.9 Switching on the cooling system

Page 96 of 185
7. Fit the table onto the drive axle.
8. Insert the 4 Allen screws of the table and tighten cross-wise.
NOTICE!
The nominal cooling capacity can only be reached
if the ambient temperature at the cooling aggregate
is below 30 °C.
Ensure sufficient air circulation.
See chapter "Installation".
Side-mounted cooling system
The side-mounted cooling system can be put into operation
without any previous preparatory work.
External cooling system
The cooling register must be connected to the external cooling
system via a feed hose and a return hose.
Top-mounted cooling system
The top-mounted cooling system must be filled with cooling
liquid before it is put into service.
2013-02-19
