Infors HT Multitron Pro Operating Manual page 90

Multitron Pro - Incubation Shaker
Installation and initial operation
Base frame
Procedure
Fig. 62
Page 90 of 185
Units with a base frame must be levelled using the adjustable feet.
The unit must be levelled on initial installation or if it is relocated.
NOTICE!
If the incubator shaker is resting on a slippery
surface, place a non-slip mat under each foot.
1. Release the locknut of the leveling foot.
2. Set the shaking speed of all units in the stack to 50 rpm.
3. Start the shakers.
4. Check the stacked units for vibrations or uneven operation.
5. In the event of vibrations or uneven operation, adjust the
levelling foot upwards or downwards with an open-end wrench
(19 mm) until the stacked units operate smoothly.
6. Check the smooth running of the units in increments of
50 rpm.
7. Adjust the levelling foot if the unit vibrates or does not operate
smoothly.
8. Release the locknut of the levelling foot.
2013-02-19
